1.5.2 Reading Fault Codes
●
The "Reading Fault Codes" function is used to read and display the
current system fault information.
1.5.3 Clearing Fault Codes
The "Clearing Fault Codes" function is used by the user to clear the
●
system fault codes and eliminate the fault indicator light after com-
pleting the diagnosis and repair of the fault problem.
1.5.4 Reading Data Streams
●
The "Reading Data Streams" function allows the user to view the
real-time working status of various sensors in the vehicle, in order to
understand the vehicle's operating conditions and assist in trouble-
shooting and fault analysis.
Module Information
Calibration ID number
Calibration ID
VIN
F1-[Esc]
Read Fault Code
Code： P0122
State： None
Throttle Position ( Sensor A) Circuit Low lnput
F1-[Help]
Live Data Stream
Engine speed
Engine temperature
lgnition timing advance (cylinder 1)
Intake air temperature
Manifold pressure (absolute)
F1-[All]
8
1/3
487D596F
0034468840270090
LE4HG4HB6EL115665
Figure 7 -
Module
Information
1/8
Figure 8 -
Fault Code
Information
F3-[Freeze]
1/7
Figure 9 -
Data Stream
Selection
F3-[Done]
