200NDIN5CKxx
E N G L I S H
LIST OF FIRST LEVEL VARIABLES
(User level)
MEANING
Var
Temperature differential in relation to principal
SET-POINT
< Range: 0.2 ÷ 10,0°C >
r0
Expressed in absolute values and defines hysteresis
(positive if mOd=0 or negative if mOd=1) of
temperature in relation to SET POINT.
Defrosting interval
< Range: 0 ÷ 24 hours >
d0
If d0=0 defrosting is excluded.
Delayed defrost for the second evaporator
<Range: 0 ÷ 10 sec > - 0 = contemporary start
The defrost process of the second evaporator starts
dd2 seconds after the defrost process of the first
evaporator. This avoids overloading the electrical
dd2
system during the defrost process in the event of
limited power. When dd2=0, defrost processes 1
and 2 start simultaneously.
dd2 is forced to 0 if d1 = 1 or 2. (Cycle inversion
defrosting)
Defrosting 1 end set point
< Range:-35 ÷ 45°C >
Defrosting 1 is not performed if the temperature
d21
read by the defrosting probe is higher than value
d21. (In the event of a defective probe, defrosting 1
is performed on a time basis.)
Defrosting 2 end set point
< Range:-35 ÷ 45°C >
Defrosting 2 is not performed if the temperature
d22
read by the defrosting probe is higher than value
d22. (In the event of a defective probe, defrosting 2
is performed on a time basis.)
Maximum defrosting time
d31
< Range: 1 ÷ 240 min >
Maximum defrosting time
d32
< Range: 1 ÷ 240 min >
Dripping duration
< Range:0 ÷ 10 min >
d7
At completion of defrosting the compressor and fans
remain inactive for the set period of time d7 and the
defrosting LED on the front of the board flashes.
Fan stop after defrosting
< Range: 0 ÷ 10 min >
Keeps fans inactive for a period of time F5 after
F5
dripping. This period is timed from the end of
dripping. If dripping is not set, the fans pause directly
after defrosting.
Minimum temperature alarm
< Range: - 45 ÷ (A2-1)°C >
Absolute temperature referred to by the ambient
probe below which, following the ALD delay, the
A1
LOW temperature alarm is triggered, activating the
buzzer (if present) and showing the letters EL
alternating with the temperature on the display, as
well as the flashing alarm icon.
Maximum temperature alarm
< Range: (A1+1) ÷ 99°C >
Absolute temperature referred to by the ambient
probe above which, following the ALD delay, the
HIGH temperature alarm is triggered, activating the
buzzer (if present) and showing the letters EH
A2
alternating with the temperature on the display, as
well as the flashing alarm icon. When the alarm is
reset the alarm icon remains on without flashing to
indicate that the event occurred, until the UP key is
pressed.
Evaporator 1 probe temperature display
< °C >
tE1
(does not display anything if dE1 =1)
Evaporator 2 probe temperature display
< °C >
tE2
(does not display anything if dE2 =1)
Evaporators defrost enabling in real time
With d0=0 and dFr=1 it is possible to set up until 6
dFr
defrosts in real time in one day through the
parameters d41...d46
Evaporators defrosts times programming
It's possible to set up to 6 times for defrosts (from
00,0 ÷ 23,5 )
dF1
The time is in the mode HH.M where HH represents
..6
the hour and M the ten minutes (i.e. 0=0 min.; 1=10
min. etc.). The winking point (.) shows that it's
displayed a time and not a temperature.
Day start time programming (from 00,0 ÷ 23,5 )
Valid if there are no night digital inputs
tdS
(see In1, In2, In3)
Day end time programming (from 00,0 ÷ 23,5 )
tdE
Valid if there are no night digital inputs
(see In1, In2, In3)
LIST OF SECOND LEVEL VARIABLES
(Installer level)
Var
MEANING
Number of evaporators < Range: 1 ÷ 2 >
Configuring nrE=1 disables evaporator 2 probe
nrE
input. It becomes a second digital input (DI2).
Fan status with compressor off
< Range: 0 ÷ 2 >
0 = Fans in continuous operation
F3
1 = Fans ON only with compressor ON
2 = Fans disabled
Gebrauchs- und Wartungsanleitung / Use and maintenance manual
Elektronischer Temperaturregler / Electronic thermostat
Fan pause during defrosting < Range: 0 ÷ 1 >
F4
0 = Fans ON during defrosting
1 = Fans OFF during defrosting
FAN disable TEMPERATURE < Range: - 45 ÷ 99°C >
The fans remain disabled if the temperature value
read by the evaporator probe is higher than the
Fst
DEF.
value of this parameter. The fans are re-enabled
with the evaporator probe deactivated or in error.
Fst. differential
Fd
< Range: 1 ÷ 10°C >
2,0
Evaporator 1 probe exclusion < Range: 0 ÷ 1 >
0 = Evaporator 1 probe present
1 = Evaporator 1 probe absent. By excluding the
dE1
evaporator probe, defrosting occurs cyclically
4
based on d0 period and terminates upon the
elapse of d31 time.
Evaporator 2 probe exclusion < Range: 0 ÷ 1 >
0 = Evaporator 2 probe present
1 = Evaporator 2 probe absent. By excluding the
dE2
evaporator probe, defrosting occurs cyclically
based on d0 period and terminates upon the
10
elapse of d32 time.
Defrosting type < Range: 0 ÷ 2 >
0= Heating element
1= Cycle inversion (hot gas)
d1
2= Cycle inversion (hot gas) with basin
3= Heating element with temperature control
Defrost at Power-on
15
< Range: 0 ÷ 1 >
dPo
0= Disabled
1= Defrost at Controller power on (if possible)
Smart defrost
0 = disabled
dSE
1 = enabled
15
Smart defrost Setpoint (if dSE=1)
< Range: -30.0 ÷ 30.0°C >
dSt
The counting of the time between the defrost is
incremented only if the compressor is ON and the
25
evaporator temperature is less than dSt.
Minimum time between each turning off and on of
25
C1
the compressor < Range: 0 ÷ 15 min >
Duration of compressor ON time in the case of faulty
ambient probe (emergency mode).
0
< Range: 0 ÷ 240 min / 0=Disabled >
If CE1=0 the emergency mode in the presence of
CE1
error EO remains disabled, the compressor
remains off and defrosting is prevented in order
to conserve the remaining cold.
0
Duration of compressor OFF time in the case of
faulty ambient probe (emergency mode).
CE2
< Range: 5 ÷ 240 >
Compressor timeout due to door switch opened.
< Range: 0 ÷ 5 min >
doC
When the door switch opens, the evaporator fans
turn off and the compressor continues to function
-45
for a period doC, after which it turns off.
Compressor re-activation time after door opened
(with In1 or In2 = +2 o -2)
< Range: 0 ÷ 240 min / 0=Disabled >
When the door switch opens and after the time
tdo, normal function of the control is restored,
generating the door open alarm (Ed).
Delay time of cold room light alarm signaling and
Tdo
visualization
< Range: 0 ÷ 240 min / 0=Disabled >
99
On switching on of the light with UP key and
passed the Tdo time, the E9 alarm starts. If it has
silenced and the light has not switched off on new
Tdo time limit, the alarm starts again. If an output
is set as alarm relay, the E9 alarm will excite the
relay.
Thermostat functioning mode
reading only
< Range: 0 ÷ 1 >
0 = Cold function.
mOd
1 = Hot function (in this mode defrosting and fan
reading only
disable Fst are excluded).
Digital Input DI and activation mode setting
< Range: -8 ÷ 8 >
0
8= night mode digital input (energy saving) (with
DI=1).
7= Pump-down pressure switch (with DI=1).
6= Stop defrosting remotely (DI=1) (reads leading
edge of impulse).
5= Start defrosting remotely (DI=1) (reads leading
0
edge of impulse).
4= Stand-by remotely (DI=1) (In order to indicate
Stand-By mode, the display shows Ino
alternating with the current view).
3= Man-in-room alarm (DI=1).
6,0
2= Door switch (DI=1).
1= Compressor protection (DI=1).
In1
0= Disabled.
22,0
-1= Compressor protection (DI=0).
-2= Door switch (DI=0).
-3= Man-in-room alarm (DI=0).
-4= Stand-by remotely (DI=0) (Ino alternating with
the current view is displayed to indicate stand-
by mode).
-5= Start defrosting remotely (DI=0) (reads leading
DEF.
edge of impulse).
-6= Stop defrosting remotely (DI=0) (reads leading
1
edge of impulse).
-7= Pump-down pressure switch (with DI=0).
-8= night mode digital input (energy saving) (with
DI=0).
1
Expert nano LINE
Digital Input DI2 and activation mode setting
1
< Range: -8 ÷ 8 >
8= night mode digital input (energy saving) (with
DI=1).
7= Pump-down pressure switch (with DI2=1).
6= Stop defrosting remotely (DI2=1) (reads
99
leading edge of impulse).
5= Start defrosting remotely (DI2=1) (reads
leading edge of impulse).
2
4= Stand-by remotely (DI2=1) (In order to indicate
Stand-By mode, the display shows IN4
alternating with the current view).
3= Man-in-room alarm (DI2=1).
2= Door switch (DI2=1).
0
1= Compressor protection (DI2=1).
In2
0= Disabled.
-1= Compressor protection (DI2=0).
-2= Door switch (DI2=0).
-3= Man-in-room alarm (DI2=0).
0
-4= Stand-by remotely (DI2=0) (IN4 alternating
with the current view is displayed to indicate
stand-by mode).
-5= Start defrosting remotely (DI2=0) (reads
leading edge of impulse).
-6= Stop defrosting remotely (DI2=0) (reads
dd2
leading edge of impulse).
0
forced 0
-7= Pump-down pressure switch (with DI2=0).
-8= night mode digital input (energy saving) (with
DI=0).
Digital Input DI3 and activation mode setting
< Range: -8 ÷ 8 >
0
8= night mode digital input (energy saving) (with
DI=1).
7= Pump-down pressure switch (with DI2=1).
0
6= Stop defrosting remotely (DI2=1) (reads
leading edge of impulse).
5= Start defrosting remotely (DI2=1) (reads
leading edge of impulse).
1.0
4= Stand-by remotely (DI2=1) (In order to indicate
Stand-By mode, the display shows IN4
alternating with the current view).
3= Man-in-room alarm (DI2=1).
0
2= Door switch (DI2=1).
1= Compressor protection (DI2=1).
In3
0= Disabled.
-1= Compressor protection (DI2=0).
-2= Door switch (DI2=0).
0
-3= Man-in-room alarm (DI2=0).
-4= Stand-by remotely (DI2=0) (IN4 alternating
with the current view is displayed to indicate
stand-by mode).
-5= Start defrosting remotely (DI2=0) (reads
5
leading edge of impulse).
-6= Stop defrosting remotely (DI2=0) (reads
leading edge of impulse).
-7= Pump-down pressure switch (with DI2=0).
0
-8= night mode digital input (energy saving) (with
DI=0).
Digital Output DO2 setting < Range: -7 ÷ 7 >
7= DO2 energised relay with defrosting 2 function
NO.
6= DO2 energised relay with defrosting 1 function
NO.
5= DO2 energised relay with activated cold
function (evaporator solenoid). The DO1 output
is activated by the digital input, set in 1 as
0
Pump-down pressure switch (In 1=7 or –7).
4= Light room output (It is automatically activated
when the door is open and with the man in
room alarm E8) NO.
3= DO2 relay energised in night mode.
2= DO2 energised relay with DO1 energised
compressor output. Used for motor condenser
unit.
1= DO2 relay energised in alarm presence.
dO2
0= DO2 relay Deactivated.
0
-1= DO2 relay de-energised in alarm presence.
-2= DO2 relay de-energised with DO1 energised
compressor output. Used for carter resistance.
-3= DO2 relay de-energised in night mode.
-4= Light room output (It is automatically
activated when the door is open and with the
man in room alarm E8) NC.
-5= DO2 de-energised relay with activated cold
function (evaporator solenoid). The DO1 output
is activated by the digital input, set in 1 as
Pump-down pressure switch (In 1=7 or –7).
-6= DO2 de-energised relay with defrosting 1
function NC.
-7= DO2 de-energised relay with defrosting 2
function NC.
DO5 digital output operation settings
(OUTPUT WITH POTENTIAL-FREE CONTACT)
1
<Range: -7 ÷ 7>
7= DO5 energised relay with defrosting 2 function
6= DO5 energised relay with defrosting 1 function
5= DO5 energised relay with activated cold
function (evaporator solenoid). The DO1 output
is activated by the digital input, set in 1 as
dO5
Pump-down pressure switch (In 1=7 or –7).
4= Light room output (It is automatically activated
when the door is open and with the man in
room alarm E8).
3= DO5 relay energised in night mode.
2= DO5 energised relay with DO1 energised
compressor output. Used for motor condenser
unit.
Via Piacentina, 6/b - 45030 - Occhiobello (RO)
Tel : +39(0)425 762906 www.pego.it - e-mail: info@pego.it
2
3
6
1
PEGO S.r.l.
Werbung
