Electrical connections on the device
5
1
Operation
6
Button function field
Homescreen icons description
Power output settings
Manual cover mode
On/Off of production
Menu access
Menu points description
Boost
If as much chlorine as possible has to be produced in as short a time as possible (e.g. for high chlorination), the
boost mode can be activated.
In this mode, chlorine production is switched on at full power for 24 hours. If the filter pump is switched off in the
meantime and chlorine production is therefore not possible, the time stops and only starts again when the filter
pump is switched on again.
After the boost time has elapsed, the Salt Relax
ATTENTION
Boost mode produces a huge chlorine quantity. Make sure to check the chlorine content in the pool before bathing
again! Boost mode can result in high chlorine concentration which can harm people and/or pool equipment.
Power output
The power output menu allows to set the required chlorine production rate. Use the up and down arrows to select
the required chlorine production rate for your pool. To adjust chlorine production rate, manual water analysis must
be done periodically!
Cover Activate or deactivate the manual cover mode. When the pool is equipped with a cover, it is important to reduce
the chlorine production when the cover is closed, to limit the risk of chlorine over production. if the cover is
equipped with a dedicated control output, it can be plugged on the Salt Relax
production can be reduced manually in this menu. The user msut therefor activate the cover mode in this menu,
each time the pool cover is closed, and deactivate it when the pool cover is open. This features benfits from a
dedicated hortcut on the home page (
Settings Access to settings menu
1100040C-4M1201_Salt Relax NXT_Manual.indd 21 1100040C-4M1201_Salt Relax NXT_Manual.indd 21
2 3
Status field
Buttons 1 – 4
Hint : The button (1 – 4) functions depends on the "button function field"
4
Status field
Cover Closed
Boost mode
Temp dependent mode
Winter mode
continues at the production rate in which it was before starting.
NXT
)
1. Power supply
2. External control connector
3. Cover connector
4. Cell connector
input. If not, the chlorine
NXT
21
