Safety Notes
• This modell is to be used only with an operating system
designed for it (Märklin AC, Märklin Delta, Märklin Digital or
Märklin Systems).
• Use only switched mode power supply units and transformers that
are designed for your local power system.
• Pay close attention to the safety notes in the
instructions for your operating system.
• Do not expose the model to direct sunlight, extreme changes in
temperature, or high humidity.
• Can only be used indoors (dry rooms).
• Caution: The crane magnet and the crane shove can warm up
considerably during operation. There is a danger that they will burn.
• WARNING! Sharp edges and points required for operation.
Important Notes
• The operating instructions are a component part of the product and
must therefore be kept in a safe place as well as included with the
product, if the latter is given to someone else.
• Please see your authorized Märklin dealer for repairs or spare
parts.
• The warranty card included with this product specifies the warranty
conditions.
• http://www.maerklin.com/en/imprint.html
Betrieb • Operation • Fonctionnement • Exploitatie
All manuals and user guides at all-guides.com
Functions
• Suitable control components:
• Address set at the factory: 71 / 72
• No mfx functions are available.
• Addresses that can be set:
• Crane cab powered by a motor.
• Crane cab can be turned 360°.
• The crane hook can be replaced by the clamshell shovel included
• Working bucket, can be raised and lowered.
• Lighting in crane cab can be turned on and off simultaneously with
• If the address is changed (71), then the consecutive address for the
• If a reset is to be carried out on the decoder, then a reset must be
• The dil switches in the crane cab must always be set according
• The crane bridge and the crane cab are protected against over-
4
6021 Control Unit, Mobile Station, Central Station.
No automatic recognition
1-80 (Control Unit 6021/Mobile Station 60651/652)
1-255 (Central Station 6021x/Mobile Station 60653)
Can travel forward and backward.
Direction of rotation can be selected.
with the crane or by the magnet.
work light.
second decoder is also always automatically assigned.
carried out for both decoders separately.
to the use or application (see Page 5) in order to avoid damages.
Settings can only be changed as long as there is no power to the
crane.
loads at their end positions. Despite this, you must avoid continuous
operation or activation beyond the end positions.
