Inhaltszusammenfassung für PACDOG PAC Fence
- Seite 1 PACFENCEö PAC Fence & PACFENCEö PAC Fence Mini miru Instructions for use Mode d'emploi Bedienungsanleitu Istruzioni per l'uso Gebruiksaanwijzin Instruccion demanejo PACDOG • —Since198W...
- Seite 2 Introductbn 1. Einführunq 2. Caractérist@ues 2. Halsband EITVfänger Control Unit: Features arri Fixing 3. Umté de Commande : Csactéristiques et Fixatkyt 3. Serdestation: BeschreibungundAnbringung Other Requternents 4. Autres conditions requises 4. Zusatzlich benötigte Gegenstande How the system works 5. Fonctionnement du systéme 5.
- Seite 3 Medium/Large Collar or for PAC Fence Mini Kit Only bl.Miniature Small Dog/CatCollar gl. MagLock charging cableEHG9 - for Pac Fence Mini Kit OBILY c. Mains power adaptor (13amp plug Wall fixings supplied for UK) NB Wre is not normaliysupploied with the kit Seep4 d.
- Seite 4 Control Unit: Features and Fixing a) Power input socket f) Loop-wire terminals b Power supply indicator g) Use supplied template to mark c Loop-wire zone display wall for fixings into wood or mason NB Install under coverlindoors (p 143 d) Loop-wire zone adjustment e) Collarchargirg socketfcx %düm/ Large Colbr.
- Seite 5 Other Requirements a) Loop-vire (available from most electrical wholesalers in 100 metre reels) Specification b) (Recommended) Boundary-demarcation plastic-tape. temporarily to help the dog recognisethc now boundariesduringtho initialtraining period.(See Trainingsection page 22.) Available from Plant Hire shops and Sports outlets. Autres conditions requises a) Specifications de la aoucle de Fil Métallique (vous la trouverez on bobines de 100 metres chez la plupart des grossistes en éectricité) - cåble de 1 ,5mm2 a plusieurs årnes en PVC 7/0.53 BS 6491X (ou équivalent),...
- Seite 6 How the system works The electromagnetic. active zone (A) comprises several sub-zones. The collar reacts immediately according to time and distance from the wire (w). a) Tone-only followed after 2 seconds by low level stimulus. b) Tone plus immediate medium level stimulus. c) Tone plus immediate high level stimulus (10 seconds max.
- Seite 7 Layout Overview a) The wire must form a complete loop around the area to be enclosed. starting and b) Before attempting to bury or otherwise fix the wire in place, lay the complete loop on tho surface and test that your chosen route will work to your oxpoctation (soo p21 This will facilitate any necessary later adjustment to the proposed route.
- Seite 8 Choosing the Route a) Follow natural boundary markers e.g. fence, wall, line of bushes or trees or the edge of the lawn. b) Crossing the lawn, for example, is not recommended. since the dog will not easily recognise an arbitrary boundary. Choix de l'itinéraire a) Suivez les repéres des limites naturelles, par exemple cloture, mur, ligne de buissons...
- Seite 9 Loop Wire Installation:Active Zone/Positioning a Tacked to a boundary feature. Opbrnum position dog collar height. b Laid on the surface (needing a sllghtly larger zone size). c) Buned just below the suttace. 50-100mm (2-4")- the shallower the better. d) In some areas with high mineral content, it will not be possible to bury the wire much below the surface due to local, environmental factors that can affect the zone shape and size.
- Seite 10 Avoid Signal Pick-up! a) Do not lay the cable parallel to incoming conductive (metal) services — e.g. electricity cables or water pipe —since this might cause stray signals to affect the dog's collar in the house, b To avoid this, always cross such services at right angles. c If the loop-wire is attached to a wire mesh fence it Will pick-up and radiate the signal.
- Seite 11 Tips for laying the wire If burying the cable or laying it on the surface. consider . a) protecting it from excessive wear (e.g. when running across a gravel driveway) or accidental damage (e.g. by a gardener's spade or lawn mower) by running it through a protective sheath e.g.
- Seite 12 Other tips for a tidy installation If using plastic piping to sheath the wire, to avoid difficulty in threading the wire through long sections: a) use shorter sections of pipe, joining them using short sleeves of larger cross-section pipe b) use cable clips (available from all electrical wholesalers) to tack the loop-wire to fences or walls.
- Seite 13 Joining the Loop-wire Loop 'Mre Connector Standard connector: a) Strip both ends of the wire to 5mm (W) b) Slide shrink-sleeve over one of the wires 5 mm (0.2 inch) c) Join the two ends together using the metal connector d) Wrap joint tightly with the PVC tape e) Slide sleeve over the assembly and shrink it with gentle heat.
- Seite 14 Twisting the Loop-Wire a).When the loop signal needs to be cancelled twist an incoming and outgoing section b) Ensure twists are close enough to cancel signal Torsion de la Boucle a).Lorsque le signal de la boucle doit étre annulé. torsadez une section entrante et sortante b) Verifier si Ies torsades sont suffsamment...
- Seite 15 Locating the Control Unit Position the Control unit somewhere under cover, protected from the weather where it can be seen on a regular basis to Check: a) power source b the continuity of the loop and c the nominal size of the zone An ideal place Would be next to tho door through Which tho dog(S) go in and out of the house, or in an easily accessible shed or garage.
- Seite 16 Linking to the Control Unit a Twist the loop-wire tails all the way from the perimeter to the Control Unit. b Connect loop-wire tails (stripped by 1/4") to terminals by firmly pressing white levers towards the circuit board (NB these levers are necessarily quite stiff) c) Connect power supply from the mains adapter or car battery (using optional clip connector) to the control unit.
- Seite 17 Typical Installation example a) Loop-wire tails are twisted all the way from the perimeter to the control unit b) Loop-wire can be twisted and re-opened to create a satellite loop around the swimming pool and/or flowerbed. Twisted section gives dog free access. c) The wire can be buried and sheathed in a protective, plastic conduit to run beneath the driveway.
- Seite 18 Fitting the Collar and Maintenance a) Ensurethatthe collar is correctlyand snu ly positionedon the dog's neck. Inspect for skin irritation on a dally basis. or longhaired breeds use the pointed Drobes. Avoid leaving the PAC collar on for over 12 hours per day and wash the dog's neck area weekly.
- Seite 19 Charging the Medium/Large Dog Collar a Charge collar before use; then each 2weeks duncnpgallignk and e very 2-4 w eeks thereafter. 4)LE lightONagain forfull 16hourscharge; '5)LED lightgoe OFF(charge complete) NB Charge cycle restarts automatically våtever collar is plugged in.Do not charge same collar within 24 hours.
- Seite 20 Charging the PAC Miniature Small Dog/Cat Collar Collar does not charge on the FC4 Control Unit, please use the seperate USB chargers enclosed. 2 hrs I. Attach the CHG9 Charging cable to the charge contact on thecollar, it will latch magnetically into place, then attach to the USB charger and plug into a socket.
- Seite 21 System Set-up: Changing the Zone Size a) The zone size is adjusted turning the blue potentiometer.(you may use a screwdriver to assist if you wish) Full anti-clockwise (7 0'clock) min zone size. Turning gradually clockwise increases zone see up to (5 0'clock) max zone size (about 3 metres) b) Tho zono LEDs will act as a guido to zono Size.
- Seite 22 System Set-up: Testing a) The distance from the Wire the collar first emits a tone warning indicates zone size. b) Check that the battery is fully charged c) Check at several points on the perimeter to ensure the collar and loop are working properly and consistently (i.e.
- Seite 23 Training: Phase 1 Training-Phase 1 Setup and Introduction (1-3 days) a Use marker fags or tape to define more easily any new or weak boundary lines b To prevent unintended stimulation, isolate the probes with plastic tape or rubber s eeves Pn%duce dog to boundary (especially...
- Seite 24 Training: Phase II Stimulation Training 1-2 Days) a) Continue as in Phase I with dog on lead (but without probe isolators), concentrating on several weak areas. b) Let him linger long enough to receive a deterrent stimulation: repeat Phase I e c) Gradually tighten PAC collar to be a snug fit (see P 18) d) Ensure PAC collar iS fitted to narrowest part of his neck.
- Seite 25 010 20 Training:Phase III&IV Proofing and Confirmation (1-2 days) a) Test success to date by distracting the dog near to the zone. b) Remove his own collar (and lead) freeing him to discover for himself c) Keep an eye on him till you are confident he is 0K on his own. d) Gradually remove markers (over period of 2 weeks or more) Dressage : Phases...
- Seite 26 Going Off Site To avoid confusing the dog when taking him acrosss the loopwire boundary, remove his PAC collar and either a) transport him across by car or, if practical, by b) physically carrying him, or c) take him through a normally-closed gate for his exit on a lead. Sortie des limites Pour éviter de perturber le Chien lorsque Vous lui faites traverser la limite définie par la boucle.
- Seite 27 Troubleshooting: Collar Problems a) Battery low/empty? —Recharge see page 18&19). b) Collar fitted properly? —Tighten see page 17 ) c) Longhaired dog? —Fit pointed probes (see page17). d) Use neon tester to check impulse stimulus. Polarity unimportant. Remember, there are 2-secondS of grace in the outer sub-zone. Détection Pannes-Problémes de Collier...
- Seite 28 Troubleshooting: Loop Wire Problems? a) Alarm Warning-note location of zone lights" Check for Loop-wire continuity Circuit broken? Find break and repar. b) Zone too small? Increase (see page 20)- Not possible? Check circuit resistance. If more than I ohm/100 metres length, check tor corrosion on your pins (see page 12). c) Stray signals within permitted areas? Check Loop-wre run near to incomtng services.
- Seite 29 Troubleshooting: Control Unit Problems? a) Control unit problems are very rare. Double-check collar/wire! b) Test with a short loop (say. 20 metres) separated out to make a circle. This loop should enable you to check both the Collar unit and the Control Unit operations.
- Seite 30 EU Ireland Printed in EU OPAC Products 2018 Telephone: UK Freephone: 0800 Ireland LowCalI: 1890 361 361 International Tel: +353 5997 24690 Website: www.pacdog.ie www.pacdog.co.uk ECTION Instruction Manual for your PAC Fence & PAC Fence Mini Control S stem Experts...
