Fig. 3
Style 13 (excl. valve depressor)
1
Style 50 (incl. valve depressor mounted into
machined flare)
Catalogue Section 7
Pressure connections
2
2
3
Fig. 4
1. 75 cm capillary.
2. 7/16 - 20 UNF flare nut.
3. copper sealring
Issue 09/01/2003
Fig. 5
Style 15
1/4-18NPT (female)
Fig. 6
Style 5
7/16-20 UNF
© 2002 Johnson Controls Inc.
Code No. PD-V48-E
