Ammonia (NH3) applications
For all larger valve types an ammonia element is
available. These elements have style 15
pressure connection and consist of a stainless
steel bellow in a steel cup (coated). The existing
element can be replaced by this ammonia
element. The pressure range does not change.
For the high range valves the spring inside the
power element has to be placed in the ammonia
element. If low-pressure range is needed this
spring can be removed. For low quantities you
have to order the selected valve and separate
ammonia replacement power element (see valve
type selection table). For quantity orders a
special valve type can be set up. Then please
contact the JC sales office in your region.
Each KIT contains parts as
indicated in the table below.
The complete KIT must be
ordered that contains part
required.
Valve type KIT number
V48AB STT15A605R
V48AC STT16A604R
V48AD STT17A616R
V48AE STT17A617R
V48AF STT17A604R
V48BC STT16A605R
Catalogue Section 7
Renewal KITs
2 2 - 1 2
2 2 - 1 2
2 2 - 1 2
2 2 - 1 2
- 1 2 - -
2 2 - - 2
Repair and replacement
Diaphragm kits can be ordered for all valves.
Also the complete power element can be
replaced. For a total revision of the valve a
renewal kit can be ordered. For type numbers of
replacement power elements, renewal kits and
diaphragm kits see valve selection table.
If a replacement is ordered a "repair parts and
service instruction" sheet will be included in
which a step by step description is given to
disassemble/assemble the valve.
1 2 4 2
1 2 4 2
1 2 6 1
1 2 6 1
- 2 6 1
1 2 4 2
V48
Issue 09/01/2003
1 - 1 - -
1 - 1 - -
1 - 1 1 -
1 - 1 1 -
- 1 1 2 1
1 - - - -
© 2002 Johnson Controls Inc.
Code No. PD-V48-E
