V48
Issue 09/01/2003
Type number selection table and replacement parts
Commercial types
Item Size
inch
1
V48AB-9510 /
2
1
V48AB-9600 /
2
1
V48AB-9601 /
2
3
V48AC-9510 /
4
3
V48AC-9600 /
4
3
V48AC-9601 /
4
V48AD-9510 1
V48AD-9600 1
V48AD-9601 1
1
V48AE-9510 1 /
4
1
V48AE-9600 1 /
4
1
V48AE-9601 1 /
4
1
V48AF-9300 1 /
2
1
V48AF-9301 1 /
2
Item
power elem.
V48AB-9510 Not available
V48AB-9600 246-824R
V48AB-9601 246-824R
V48AC-9510 Not available
V48AC-9600 246-825R
V48AC-9601 246-825R
V48AD-9510 Not available
V48AD-9600 246-925R
V48AD-9601 246-925R
V48AE-9510 Not available
V48AE-9600 246-925R
V48AE-9601 246-925R
V48AF-9300 246-758R
V48AF-9301 246-671R
Sea-water types
Item Size
inch
3
V48BC-9600 /
4
Item
power elem.
V48BC-9600 246-825R
© 2002 Johnson Controls Inc.
Code No. PD-V48-E
Range Refrig. Capil.
bar connec. length
4 / 20 style 50 0.75
4 / 16 style 13 0.75
1.5/ 7.5 style 13 0.75
4 / 20 style 50 0.75
4 / 16 style 13 0.75
1.5/ 7.5 style 13 0.75
6 / 20 style 50 0.75
4 / 16 style 13 0.75
1.5/ 7.5 style 13 0.75
6 / 20 style 50 0.75
4 / 16 style 13 0.75
1.5/ 7.5 style 13 0.75
6 / 14 style 5
1.5/ 9 style 5
Replacements
renewal kit
STT15A605R
STT15A605R
STT15A605R
STT16A604R
STT16A604R
STT16A604R
STT17A616R
STT17A616R
STT17A616R
STT17A617R
STT17A617R
STT17A617R
STT17A604R
STT17A604R
Range Refrig. Capil.
bar connec. length
4 / 16 13 0.75
Replacements
renewal kit
STT16A605R
Connection
thread
ISO 228 - G 1 / 2
ISO 228 - G 1 / 2
ISO 228 - G 1 / 2
ISO 228 – G3/ 4
ISO 228 – G3/ 4
ISO 228 – G3/ 4
ISO 7 – Rc1
ISO 7 – Rc1
ISO 7 – Rc1
ISO 7 – Rc1 1 /4
ISO 7 – Rc1 1 /4
ISO 7 – Rc1 1 /4
ISO 7 – Rc1 1 /2
-
ISO 7 – Rc1 1 /2
-
diaphragm kit
KIT016N601 (100)
KIT016N601 (100)
KIT016N601 (100)
KIT016N602 (100)
KIT016N602 (100)
KIT016N602 (100)
KIT016N603 (50)
KIT016N603 (50)
KIT016N603 (50)
KIT016N603 (50)
KIT016N603 (50)
KIT016N603 (50)
KIT016N604 (25)
KIT016N604 (25)
Connection
thread
ISO 228 – G3/ 4
diaphragm kit
KIT016N602 (100)
Weight Quantity Weight
single per per
pack kg. box box kg.
2.3 1 2.3
2.3 1 2.3
2.3 1 2.3
3.0 1 3.0
3.0 1 3.0
3.0 1 3.0
5.5 1 5.5
5.5 1 5.5
5.5 1 5.5
7.5 1 7.5
7.5 1 7.5
7.5 1 7.5
11.5 1 11.5
11.5 1 11.5
Ammonia
element type
Not available
Not available
Not available
Not available
Not available
Not available
246-667R
246-667R
246-667R
246-667R
246-667R
246-667R
246-781R
246-781R
Weight Quantity Weight
single per per
pack kg. box box kg.
3.0 1 3.0
Ammonia
element type
Not available
Catalogue Section 7
