RF Rx SW868/SW915/SW917/SW922-4S
Montage- und Anschlussanleitung / Funk-Empfänger
Mounting and wiring instructions / Wireless receiver
English
Start-up
Requirements:
- Mount device on standard DIN rail.
- Connect cable for supply voltage 24 VDC.
- A maximum of 40 transmitters can be taught in parallelly.
- The green LED indicates operational readiness.
The orange LED indicates the state of the output:
Off - Transmitter taught in, but inactive
On - Transmitter taught in, active
LED 1 flashes - No transmitter taught in

Configuration mode

The receiver's operating modes and the behaviour of the transmitter
are set here.
Start configuration mode:
- Press and hold the LRN button for 10 s
→ the MD LED flashes quickly (5 Hz).
- Release the LRN button
→ LED1 flashes once with a 1-second pause.
Navigation in configuration mode:
Objective Action
Current menu item
Vertical navigation Press the LRN but-
ton briefly (< 1 s).

Horizontal Press and hold the
navigation  LRN button for at
least 1 s.
Save configuration Press and hold the
LRN button for at
least 1 s.
Cancel Press and hold the
configuration  LRN button for
>10 s or button
timeout ≥ 5 min.
Overview of configuration mode: see Figure p. 10.
Select operation mode
These settings relate to the behaviour of the receiver. There are three
function groups for this: »Relay function«, »Transmitter function« and
»Additional function«. The relay function is used to set the behaviour
of the switching relays. The transmitter function enables a logical link
(with several taught-in switches per channel), current impulse func-
tion or wiper function. The additional options »Battery monitoring«
and/or »Status monitoring« are used to monitor the wireless switches.
Operating
mode
Standard
Standard,
inverse output
Relay energised
Relay energised,
inverse output
Standard
Blinking behaviour
Link
LED 1 flashes seve-
ral times
Latching
function
Wiper
function
Cancellation con-
firmation: LED MD
and LED 1 flash 6
times quickly.
6 / 16
Blink-Code LED 1
Relay functions
1 – 1 – 1
1 – 1 – 2
1 – 1 – 3
1 – 1 – 4
Transmitter functions
1 – 2 – 1
AND 1 – 2 – 2 – 1
OR 1 – 2 – 2 – 2
EX-OR 1 – 2 – 2 – 3
1 – 2 – 3
0,5 s 1 – 2 – 4 – 1
1 s 1 – 2 – 4 – 2
2 s 1 – 2 – 4 – 3
5 s 1 – 2 – 4 – 4
120 s 1 – 2 – 4 – 5
300 s 1 – 2 – 4 – 6
600 s 1 – 2 – 4 – 7
flexible 1 – 2 – 4 – 8 – 1...600
Function
Relay energises
when actuated
Relay de-energises
when actuated,
inverse output
signal.
Relay energises
when operating
voltage is applied.
Relay energises
when operating
voltage is applied,
inverse output
signal.
The output takes
on the last switch
status received.
The following links
can be selected:
OR, AND, EXCLU-
SIVE-OR.
Latching function /
impulse function
Wiper function,
contact drops out
automatically after
set time. In additi-
on to the predefi-
ned times, a flexi-
ble time between
1 and 600 s can be
selected.
