RF Rx SW868/SW915/SW917/SW922-4S
Montage- und Anschlussanleitung / Funk-Empfänger
Mounting and wiring instructions / Wireless receiver
English
Use of the mounting and wiring instructions
All actions described in these instructions may only be performed by
qualified persons who have been trained and authorised by the
operating company.
1. Read and understand these mounting and wiring instructions.
2. Comply with the valid occupational safety and accident prevention
regulations.
3. Install and operate the device.
Selection and installation of devices and their integration in control
systems demand qualified knowledge of all the relevant laws, as well
as the normative requirements of the machine manufacturer. In case
of doubt, the German language version of these instructions shall
prevail.
Scope of delivery
Device, mounting and wiring instructions, packaging.
Intended use
The four channel radio receiver is used to switch electrical loads via
radio transmission. The transmitters must support the steute
Wireless protocol.

Product features

- Input: designed for 24 VDC.
- Outputs: potential-free mechanical relays.
For details, see technical data.
Option status memory
After power-on with the receivers with status memory
RF Rx SW868/ 915/917/922-4S-S, the last valid status of the outputs
is re-established.
Antenna
Use suitable antennas only:
Device Antenna
SW868/922 Antenna with cable and SMA
plug-in connector
SW915/917 Antenna with cable and SMA
plug-in connector
Mount the antenna on a metal plate. The metal plate serves as an
HF counterweight. Minimum size of metal plate: 250 x 250 mm. Note
minimum sideways distance to nearest wall or disturbance source:
>300 mm. Do not bend or clamp the cable. Minimum bending range of
cable: >25 mm.
Mat. No. Receiver SET incl. stick-on antenna
1373201 RF Rx SW868 4S 24VDC (SET)
1373187 RF Rx SW915 4S 24VDC (SET)
Assignment of locations and radio frequencies:
Device type Radio frequency
SW868
SW915
SW917
SW922
Design of wireless range
The radio signal is attenuated on the way from the transmitter to the
receiver. In addition, the radio signal is influenced by obstacles. The
degree of attenuation depends on the material of the obstacle.
The following tables serve as a guide.
Penetration of radio signals:
Material
wood, gypsum, glas uncoated
brick stone, press boards
armoured concrete
metal, aluminium lamination, water
Typical ranges:
Place of use
in free field (SW868/915/917 LR)
in free field (SW868/915/917 ULR)
in free field (SW922 LR)
in free field (SW922 ULR)
indoors (SW868/915/917 LR)
indoors (SW868/915/917 ULR)
indoors (SW922 LR)
Mat. No.
indoors (SW922 ULR)
1188958
To get the maximum range: use the specified antennas. With other an-
1188987 tennas, the maximum range may differ.
Safety
Do not use the device in connection with other devices whose direct or
indirect purpose is to ensure life or health, or whose operation may
pose a threat to humans, animals or material assets.
N.B.
Subject to technical modifications. Reconstruction and alterations to
the device are not allowed. It is the responsibility of the manufacturer
of a plant or machine to guarantee the correct general function.
5 / 16
Location
868.3 MHz EU
915.0 MHz USA
Canada
Mexico
917.0 MHz Brazil
916.5 MHz Japan
Penetration
90...100 %
65...95 %
10...90 %
0...10 %
Wireless range (approx.)
450 m
700 m
150 m
230 m
40 m
50 m
20 m
25 m
According to
2014/53/EU (RED)
FCC
IC
IFT
ANATEL
ARIB STD-T108
