4. Take off freezing chamber door, dismantle bottom hinge, hole caps.Install
shaft of bottom hinge on the other side and install the bottom hinge on the
other side of bottom beam．
5. a) Remove the upper cover of refrigerating chamber door, install the upper
hinge sleeve, door signal line to the other side and install the door upper cover.
Dismantle the stopper and sleeve pipe from the right bottom of freezing
chamber door, take out another spare stopper(for reversible door),
and assemble the sleeve pipe and spare stopper on left bottom of door by
screw install the upper hinge sleeve, door signal line to the other side and
install the door upper cover.
b)Dismantle the stopper and sleeve pipe from the right bottom of freezing
chamber door, take out another spare stopper(for reversible door),
and assemble the sleeve pipe and spare stopper on left bottom of door by screw.
Take off the sleeve pipe and hole caps on the freezing chamber door and
mount it on the other side.
door upper cover
a
door signal line
sleeve pipe
sleeve pipe
stopper
stopper screw
08
shaft
shaft
hole cap
bottom hinge
b
sleeve pipe
stopper
stopper screw
EN
