• To remove the eyepiece, press the eyepiece lock
on the base body forward (in the direction of the
lens) and twist the eyepiece to the left (counterclo-
ckwise) until it can be removed.
adjustment of the screw-in-typ eye cup
Use without eyeglasses:
Turn the eye cup (counter-
clockwise) until it stops.
Use with eyeglasses:
Turn the eye cup (clock-
wise) until it stops.
Use of the zoom eyepiece
To change magnification:
Turning
ring to the right (clockwise)
decreases magnification.
Turning
increases the magnification.
DE EN
All manuals and user guides at all-guides.com
the
adjustment
it
to
the
left
22
You will be able to read the magnification above
the index point.
The reticle functions at any selected magnification.
The target image and the reticle magnification
change at the same time.
Focusing
• For distant objects, turn
the adjustment ring for
focusing to the right (clock-
wise).
• By turning the adjust-
ment ring to the left (anti-
clockwise), you can observe objects that are
nearer.
• In order to ensure fatigue-free observation, turn
the adjustment ring for focusing a bit to the left
(anti-clockwise) until the image becomes slightly
unsharp. Then turn the adjustment ring to the right
(clockwise) until the maximum image definition is
attained for the first time.
• To retain the image definition over the entire
range of magnification, you should carry out sharp
focusing using the zoom eyepiece with the highest
magnification.
operating the reticle brightness control
If the brightness control knob of the reticle is in the
zero/neutral position, then no reticle is visible, and
the unit can be used like a typical commercially
available spotting scope.
EN
DE
23
