overview
18
All manuals and user guides at all-guides.com
1 Protective cap for objective lens
2 Sunshield
3 Tripod ring
4 Adjustment ring for focusing
5 Dioptric correction for reticle
6 Brightness control knob
7 Battery compartment, including battery CR123
8 Protective cover for bayonet
9 Locking mechanism
10 Locking screw
11 Tripod base
12 Connection thread for tripod
13 Cover screws for mounting rail attachment
14 Coin opener
15 Support for the spotting scope rail
16 Eye piece
17 Adjustment ring for changing magnification
18 Protective cap for bayonet
19 Protective cap for eye piece
please find our current product accessories at www.SwarovSkIoptIk.com.
