2. If dishwasher is installed at the corner of the cabinet,
there should be some space when the door is opened.
Depending on where your electrical outlet is, you may
need tocut a hole in the opposite cabinet side.
EN
Step 2. Aesthetic panel's dimensions and installation
Follow the specific installation instruction for attaching the
aesthetical door panel.
Semi-integrated model
Seperate velcro stripe A and velcro stripe B and attach velcro stripe A on the inner
side of the aesthetic panel. Attach the felted velcro stripe B on the outer door of
dishwasher (see figure A). After positioning of the panel, fix the panel onto the
outer door by screws and bolts (See figure B).
A
Velcro
stripe
1.Take away the four short screws
B
2.Pin up the four long screws
15
Dishwasher
Cabinet
Door of
dishwasher
Minimum space
of 50mm
