Adjustable nozzle (Fig. G1): Spot spraying flower beds,
walkways, driveways, patios, and around trees and
shrubs. Edging along fences, driveways, and walkways.
Killing brush.
Fan nozzle (Fig. G3): Flat spray for very broad coverage
and higher viscosity liquids. Preparing large areas for
planting.
G-1 Fan Nozzle G-3 Foaming Nozzle
G-2 Shower Nozzle
Shower nozzle (Fig. G3): Puts out higher flow of water for
watering and treating plants.
Foaming nozzle (Fig. G3): Visibly marks treated weeds.
Spot spraying weeds in lawn, around flower beds,
trees, and shrubs. Edging along fences, driveways, and
walkways.
The adjustable nozzle can be adjusted between stream and
spray (Fig. G1).
1. Turn the knurled (textured) part of the nozzle
counterclockwise for stream.
2. Turn the knurled (textured) part of the nozzle
clockwise for spray.
Unscrew the whole nozzle counterclockwise to remove and
change nozzle (Fig. G2).
Flow rate of different nozzles coming with the
sprayer:
Maximum
Nominal
Working
Flow Rate
Pressure
(L/min)
(L/min)
Adjustable
2.3 2.7
Nozzle
Fan Nozzle
2.3 2.7
Shower
2.3 2.9
Nozzle
Foaming
2.3 2.7
Nozzle
SPRAYING HOME-AND-GARDEN CHEMICALS (FIG. H)
WARNING:
Never point the nozzle of the wand at
yourself or others.
56 VOLT LITHIUM-ION CORDLESS BACKPACK SPRAYER — BSP3500E
WARNING:
operating the sprayer.
WARNING:
animals; always spray downwind.
WARNING:
be well-ventilated and away from sparks or flames.
1. Install the battery pack.
2. Turn the speed dial to set a desired flow rate.
3. Aim the sprayer nozzle directly at the plants or objects
you wish to spray.
NOTE:
Make sure to stand far enough from the object
being sprayed to prevent the spray from splashing back
onto you.
4. Depress the trigger to start the sprayer.
5. Release the trigger to stop the sprayer.
6. Always drain and clean the tank after every use as
directed in the "MAINTENANCE" section.
OPERATING TIPS
◾
Adjust the shoulder straps of the harness, so that the
sprayer sits above your waist and the tank is close
against your back.
◾
Avoid spraying on windy days. Spray can be
accidentally blown onto plants or objects that should
not be sprayed.
◾
Spray in the early morning or late afternoon, especially
Optimum
in warmer weather. Excessive heat can evaporate the
Working
spray before it settles.
Pressure
(L/min)
MAINTENANCE
2.4
WARNING:
replacement parts. Use of any other parts may create a
hazard or cause product damage. To ensure safety and
2.4
reliability, all repairs should be performed by a qualified
service technician.
2.7
WARNING:
the battery pack from the sprayer before servicing,
2.4
cleaning, changing nozzles, performing any maintenance or
when the sprayer is not in use. A battery-operated sprayer
with the battery pack inserted is always on and can start
accidently.
Never smoke, eat, or drink while
Never spray in the direction of people or
Risk of fire or explosion. Spray area must
When servicing, use only identical
To avoid serious personal injury, remove
