OPERATING AND ASSEMBLY MANUAL
One-time setup of shuttle
Fig. I:
Insert the bar for the backrest (1) into the frame until it audibly
clicks in.
Fig. II:
Attach the seat (2) to the frame (3). Then zip the zipper around
the bar of the backrest. In addition, attach the seat and the
footrest to the frame with the hook-and-loop fasteners.
One-time attachment of holding fixtures
Fig. III:
Attach the holding fixtures of the shuttle (4) from below the
rear axles of the buggy. Pay attention to the arrows, which
should be pointing in the driving direction, as well as the labels
‚L' for left and ‚R' for right facing the driving direction.
Then you can insert both holding brackets (5) from above into
the holding fixtures and attach them with two screws (6) on
the underside.
Attaching and using the shuttle
Fig. IV:
Hang the shuttle into the holding fixtures with the adapter bar
until it clicks in audibly. If you would like to remove the shuttle,
push the locks (7) back and remove the shuttle (8).
Fig. V:
Buckle the 5-point-harness (9) once the child is seated in the
shuttle. For safety, also buckle the belt located at the child's
feet, so that wour child cannot reach into the moveable parts
of the buggy.
Fig. VI:
When you are not using the shuttle, you can lock it onto the
buggy with a lock (11) at the front.
