Code Set Up
A Set Up by brand code:
According to the attached Device Brand
Code List, find out the code of the device
brand and device code that you wantto
control. For example, you can find codes
for SONY TV: 010, 011, 028, and 030... Then
follow the steps as below.
a Press and hold the [SET] key Then press
the device key that you want to control,
such as [TV].
b The LED will be on at moment. Then
release the pressed both keys
c Enter in the 3-digit Device Code (for exam
pie: code 010under SONY TV)
d If the entered Device Code is correct, the
LEDwill be off automatically, then gone
to step e. If it is incorrect, the LEDwill blink
twice and keep being at set up mode, then
return to step c
e Try if keys on remote control work or not.
If none key works or some key work but
most keys work improperly, please try
other codes in the same brand (for
example: code 028,030 ..under SONYTV),
repeat step a-e till you find one code
which work good enough
Remark: In the process of setup, if you want
to quit from setup mode, please press device
key. (If no key pressed in 10 seconds, the
remote control will leave the set up mode
automatically.)
B Set Up by Manual Search:
After you have set up by device brand
code several times, the remote control still
doesn't work (i.e. The device still can not be
controlled bythis remotecontrol),or you can
not find the correct code in the Device Brand
Code List, you can use „Manual Search" to
6
find out the reactive Code:
a. Power on the device that you want to
control.
b. Pressand hold the [SET]keys.Thenpress
the device key in remote control, such as
[TV], etc
c. The LED will be on at moment. Then
release the pressed keys.
d. Point the remote control to the device,
strike the [POWER] key. the remote control
enters into" Manual Search" mode and the
LED keeps flashing.
e. See if device reacts or not. If it works, turn
to step f•,If not, repeat step d every 1
second.
f Test other keys If keys work well enough,
press the device key to quit from the
search mode. If most keys don't work well
enough, repeat step d-fto find the best
code.
Remarks:
• Whenever you wantto leave or change
search mode, press the device key to quit,
and the LED will turn off.
• In the Manual Search Mode, besides the
[POWER] k ey (POWER]key,all other keys'
function can be checked normally. That is
to say you can test other keys without
eaving Manual Search mode. It will leave
Manual Search mode automatically if no
key pressed in 30 seconds.
• You may use the SET keyto change the
search direction from forward to backward
or from backward to forward
C Set up by Auto Search:
This search is similar to Manuel
Search except it transmits power signal
automatically instead of manually pressing
the power key during the search:
a. Power on the device you want to control
b. Pressand hold [SET]key,in the meantime,
press and hold the Device key that you
want to control
(for example: TV) for more than 3 seconds
and then release them, the auto search
begins. The remote control enters into
Auto Search, LED flash, and remote control
transmit power signal every 2.0 second
automatically.
c. See if device react or not, once the device
reacts, press anykey (exceptSETkey)to
stop the search.
d Test if other keys work well enough. f
most keys work not good enough, Auto
Search again to find next reactive code
and try until you find the best code.
Remark:
a. You must point your remote control to the
device that you want to control during
Auto Search.
b. Whenever you want to leave Auto Search
mode, press any key (except SET key) to
quit, and the LEDwill be Off. The search is
over.
c. When remote control search through a
codes (about 10 minutes), then the remote
control will quit from Auto Search process
automatically.
n case of you did not stop the search on
d
time when device reacted, you may use
the Manual Search to search back to find
the passed code
D. Set up byDevice Code Display
The device code is a 3-digit number and any
one of the 3 digits can be indicated:
Strike the device key which code no You
want to display.
2. Pressand hold the [SET]key,in the mean
time press the digit that you want to
display, such as 1,2,or3.
3. Release the both pressed keys
4. Count the times the LED blinks, and the
blinking time is the digit. If there is no blink,
the digit is zero
For example: for code 138
SET+I(first digit):
LED blinks 1 time
SET+2 (second digit):
LED blinks 3 times
SET+3 (third digit): LED blinks 8 times
Reset
Use the Reset function to erase all the set
up data
1. Press and hold the [SET]key
2. Thenpress and holdthe [01key for more
than 3 seconds.
3. Then release the both pressed keys, the
LEDwill blink twice then off, your remote
control got reset.
