10. OSD menu
a) Operation of the OSD menu
Use the buttons on either the monitor/DVR or the IR remote control.
• To enter the OSD menu, press the MENU button (2) on the monitor/DVR or on the IR remote control.
• Press the MENU button (2) again to select the desired menu.
• Use the
arrow keys (5) to select the desired menu item.
• Use the
arrow keys (5) to change the values to be set.
• Press the
button (4) to confirm a menu item.
• To exit the menu, press the ESC button (6).
b) OSD menu structure
Menu
Menu item
Time Setting
Year
Month
Day
Hour
Minute
CH1 Setting
Frame Rate
File Save
CH2 Setting
Frame Rate
File Save
REC Setting
Quality
Overwrite
Section
REC Mode
Card Info
Total Size
Remain Size
Remain File Num
Format
System setting
Language
Alarm Period
Time stamp
Reset
Version
All manuals and user guides at all-guides.com
Function
Time setting year
Time setting month
Time setting day
Time setting hour
Time setting minute
Set the frame rate for camera 1
Record channel 1 yes/no
Set the frame rate for camera 2
Record channel 2 yes/no
Set the image quality
Overwrite the oldest files if memory card full yes/no
Length of the individual recording files
Set the recording start mode (manual/automatic/motion detection)
Display the total space of the memory card
Display the remaining free space
Display the remaining number of recording files
Format the memory card yes/no
OSD language
No function for this model
Record the date and time when recording yes/no
Reset to factory settings yes/no
Display the software version
33
