Arctic Compact 5/8 lt
5
Pinch tube faucet: push the dispensing handle
(1) and take the pinch tube off from its seat (2) (see
picture 2 - page 4).
6
Gravity faucet: extract the piston and then
remove the dispensing handle (see picture 3 - page
4).
7
Slide drip tray out and empty it.
7. 3. 2 CLEANING
IMPORTANT
Do not attempt to wash any machine
components in a dishwasher.
ATTENTION
Before any disassembly and/or cleaning
procedure make sure that the dispenser is
disconnected from its power source.
1
Prepare at least two gallons of a mild cleaning
solution of warm (45-60 °C 120-140 °F) potable
water and dishwashing detergent. Do not use
abrasive detergent.
Important: if present, follow label directions, as too
strong a solution can cause parts damage, while too
mild a solution will not provide adequate cleaning.
IMPORTANT
In order to prevent any damages to the
dispenser use only a detergent suitable with
plastic parts.
2
Using a brush, suitable for the purpose,
thoroughly clean all disassembled parts in the
cleaning solution.
ATTENTION
When cleaning the machine, do not allow
excessive amounts of water around the
electrically operated components of the unit.
Electrical shock or damage to the machine
may result.
14
3
Do not immerge the lighted top covers in liquid.
Wash them apart with the cleaning solution.
Carefully clean their undersides.
4
In the same manner clean the evaporator plates
using a soft bristle brush.
5
Rinse all cleaned parts with drinking water.
IMPORTANT
The parts must not show cracks or principles
of breakage during the washing phase of the
pieces.
7. 3. 3 SANITIZING
Daily: Sanitizing should be performed immediately
prior to starting the machine. Do not allow the unit to
sit for extended periods of time after sanitization.
Sanitization must be performed whenever the
distributor is put back into operation with a new
product.
1
Wash hands with a suitable antibacterial soap.
2
Prepare at least two gallons of a warm (45-
60 °C 120-140 °F) sanitizing solution (100 PPM
available chlorine concentration or 1 spoon of
sodium hypoclorite diluted with two litres of water)
a c c o r d i n g t o y o u r l o c a l H e a l t h C o d e s a n d
manufacturer's specifications.
3
Place the parts in the sanitizing solution for five
minutes.
4
Do not immerse the lighted top covers in liquid.
Carefully wash their undersides with the sanitizing
solution.
5
Place the sanitized parts on a clean dry surface
to air dry.
6
Wipe clean all exterior surfaces of the unit. Do
not use abrasive cleaner.
7. 3. 4 ASSEMBLY
1
Slide the drip tray into place.
2
Pinch tube faucet: push the dispensing handle
(1) and insert the pinch tube into its vertical seat in
the bowl bottom(2). Lightly pull the pinch tube end
downwards til itl is well arranged (3) (see picture 4 -
page 4).
3
Gravity faucet: install the faucet handle and the
