1 ELECTRICAL SAFETY
INSTRUCTIONS
1
Before connecting the dispenser to the mains,
check that the voltage shown on the rating plate
matches your electricity supply. Connect the
dispenser to a single-phase supply through an
earthed socket as required by current regulations. If
the dispenser is to be disconnected from the power
supply using a single pole switch, the gap between
the contacts on this switch must be sufficiently wide
to guarantee full disconnection under category III
overload conditions.?
2
Do not use extension cables to connect the
appliance.
3
To avoid any risks, if the power cable is
damaged, it must be replaced by the manufacturer,
by an authorised technician or by a similarly
qualified person.
4
The dispenser is not suitable for outdoor use.
5
The dispenser must be installed in the upright
position and always handled with care. If, even
during transport, it has been positioned horizontally,
wait 4 hours after installation before starting.
6
Before cleaning,
dispenser by removing the plug from the socket.
7
Always disconnect
r e m o v i ng a ny o f t h e p a n e l s f o r c l e a ni n g o r
maintenance work.
8
This appliance must not be operated by
children.
9
Do not let children play with the appliance.
10
This appliance must not be used by children
aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or
with a lack of experience and knowledge unless
they have supervision or have been trained
regarding the safe use of the appliance and
understand the risks involved.
11
Only persons who know and have practical
experience of the appliance are permitted access to
the inner components of the dispenser, especially
when dealing with issues regarding safety and
hygiene.
2 HYGIENIC SAFETY INSTRUCTIONS
1
This appliance is intended exclusively for
domestic and similar use.
2
For the appliance to operate correctly, room
temperature must be between +5° and +32°C.
always disconnect
the dispenser before
3
Use the appliance to cool the indicated liquids
only.
4
Do not introduce dangerous or toxic liquids to
the appliance.
3 TECHNICAL CHARACTERISTICS
Transparent removable bowls
Capacity of each bowl, approx.
Dimensions:
width
depth
height
Net weight, approx.
Gross weight, approx.
Adjustable thermostats
Hermetic compressor
Air-cooled condenser
the
Overload protector
Noise level lower than 70 dB (A)
IMPORTANT
Read electrical ratings written on the data
plate of the individual units; the data plate is
adhered on the dispensing side panel of the
unit, just behind the drip tray (the right side
drip tray in multiple bowl models). The serial
number of the unit (preceded by the symbol #)
is adhered just below the right bowl. Data
plate specifications will always supersede the
information in this manual.
Specifications are subject to change without
notice.
4 INTRODUCTION
It is necessary to read all sections of this manual
thoroughly to familiarize yourself with all aspects of
the unit.
Like all mechanical products, this machine will
require cleaning and maintenance. Besides,
disp enser wo rking ca n be comp romised by
operator's mistakes during disassembly and
cleaning. It is strongly recommended that personnel
in charge of the equipment's daily operations,
5/1 5/2 5/3
8/1 8/2 8/3
n 1 2 3
l 5 5 5
8 8 8
cm 18 25 37 50
cm 39 39 39
41 41 41
5 lt cm 55 55 55
8 lt 62 62 62
5 lt kg 13 17 22
8 lt 14 17 22
5 lt kg 14 18 24
8 lt 15 19 24
n 1 1 1
5/4
8/4
4
5
8
39
41
55
62
27
28
29
30
