6. Function definition
①②③④ ⑤ ⑥
13
Serial
Interface Function definition
number
Internet
Ethernet Interface for network cable
Interface
connection
USB3.0 Connect USB flash drive \
Interface Connect wireless card \ Connect PC
USB2.0 Connect USB flash drive \
Connect wireless card \ Connect PC
Interface
Screen Used to expand other screen sizes,
interface
RJ11 type interface
WiFi antenna Receive 2.4GHz WiFi signal
6
Power interface Connect AC power supply
7. Starting up the machine
Check the power supply voltage setting on the machine to ensure that it matches the voltage of the local grid. After
confirming that the voltage gear is set correctly, the power switch of the machine is adjusted to the "I" gear, and the
LED light of the machine will automatically turn on after the power is turned on, indicating that the machine has started.
After the LED light is turned off, it means that the startup process of the machine has been completed. You can follow the
instructions of the machine and start using the machine for work or other applications.
Before connecting the power supply, be sure to check the voltage mode
according to the local grid voltage to avoid burning out the power supply.
If the local grid voltage is in the range of 100-120V, please use a screwdriver
to dial the machine's power supply voltage to 110V.
If the local grid voltage is in the range of 100-240V, please use a screwdriver
to dial the power supply voltage of the machine to 220V.
