Instruction Manual ES32S
_______________________________________________________________________________________________________________________

8. Technical Data

Type
Weight incl. battery
Cutting time
max. crimping force
Cutting range
Battery voltage:
Battery capacity:
Battery charging time:
Cycles/battery:
Ambient temperature
Hydraulic oil
Sound level
Vibrations
Remark
This Instruction Manual can be ordered free of charge. The Part No. is HE.10986
Instruction manual ES32S
_____________________________________________________________________________________________________________________
8. Technical Data
Type
Weight incl. battery
Cutting time
max. crimping force
Cutting range
Battery voltage:
Battery capacity:
Battery charging time:
Cycles/battery:
Ambient temperature
Hydraulic oil
Sound level
Vibrations
Remark
This Instruction Manual can be ordered free of charge. The Part No. is HE.10986
ES32S
approx. 1,7 kg (incl. battery)
3-8 s
approx. 15 kN
Ø 32 mm (e.g. 4 x 50 mm² NYY)
9,6 V (RAM1)
1,3 Ah (RAM1)
approx. 40 min. (LGM4), resp.
approx. 15 min. with fast-charger (LG 5)
40 cycles (e.g. H07V-R 1x240 mm² NYY)
-20°C to +40°C
Shell Tellus T 15
70,6 dB (A) in a distance of 1m
< 2,5 m/s²
ES32S
approx. 1,7 kg (incl. battery)
3-8 s
approx. 15 kN
Ø 32 mm (e.g. 4 x 50 mm² NYY)
9,6 V (RAM1)
1,3 Ah (RAM1)
approx. 40 min. (LGM4), resp.
approx. 15 min. with fast-charger (LG 5)
40 cycles (e.g. H07V-R 1x240 mm² NYY)
-20°C to +40°C
Shell Tellus T 15
70,6 dB (A) in a distance of 1m
< 2,5 m/s²
page 29
page 29
