Fluval AQUASKY 3.0 LED Bedienungsanleitung Seite 3

Scan QR code for FluvalConnect app instructions or visit
www.fluvalaquatics.com/us/fluval-connect-app-manual
MOUNTING BRACKET INSTRUCTIONS:
1. Ensure all LED fixture components are present and undamaged.
2. Adjust light fixture extendable brackets to match aquarium width. Bracket edges should rest securely on aquarium frame to ensure proper fit.
3. Connect transformer to light fixture electrical supply and plug into power source.
REMOVING THE EXISTING LIGHT TUBE
• Disconnect the T8/T5 lighting system from the power supply and do not reconnect.
• Please ensure that the LED strips are not connected to the power supply when mounting into the T8/T5 lighting system using the
mounting brackets.
• Unscrew both end caps and move them into the center of the tube.
• Remove the tube by sliding it gently out of the fitting.
INSTALLING THE MOUNTING BRACKETS
• Clip the mounting brackets over the ends of the extending arms of the LED strip, as
per the photo (A). You may need to pull out the extending arms slightly to do this.
• For T5 lighting systems: fit the end caps over the end of the mounting brackets, to
face inwards.
• For T8 lighting systems: click to fit the T8 ring adapter onto the end of each
mounting bracket, then follow the instructions above for T5 lighting systems.
• Fully tighten the end caps back onto the threads, being careful not to cross thread
or over tighten. You may need to extend or retract the extending arms to make the
LED strip fit perfectly (B).
• WARNING: Before connecting the power supply, ensure that the LED strip
is securely fastened to lighting system of the aquarium so that it is stable and
cannot fall into the water. The LEDs are tested to IPX7, which means they can
withstand temporary submersion. NOTE: THIS IS NOT A SUBMERSIBLE LIGHT.
• Connect the power supply to the LED strip and switch on.
INSTALLING THE CEILING BRACKET
• Clip the ceiling brackets over the back (side with fins) of the LED strip.
• Use suitable fixings for the intended mounting surface. If you wish to bond the brackets to glass or
plastic use aquarium silicone.
• WARNING: Do not screw the bracket onto any housing containing electrical wiring or connections,
such as lighting ballasts, due to severe risk of electric shock.
MAINTENANCE:
For maximum LED performance, it is recommended that the fixture and the LED lens be cleaned on a weekly basis. Unplug transformer prior to
cleaning the light fixture and remove from aquarium. Use both hands when manipulating this appliance. Wipe exposed surfaces carefully with a
damp cloth to remove any dust or mineral deposits that may collect over time. Do not use detergents or harsh cleaners as it can damage the light
fixture. Make sure all surfaces are dry before re-connecting the transformer to the power source.
BASIC TROUBLE SHOOTING:
If the fixture does not work, ensure that all plugs and wires are firmly connected, ie: connection from fixture to transformer, and connection from
transformer to electrical outlet.
FOR AUTHORIZED WARRANTY REPAIR SERVICE:
QUESTIONS? If you have a problem or question about the operation of this product, please let us try to help you before you return the product
to your dealer. Most problems can be handled promptly with a phone call. Or, if you prefer, you can contact us on our web site at www.
fluvalaquatics.com. When you call (or write), please have all relevant information, such as model number and/or part numbers available.
CANADA: Consumer Repair, Rolf C. Hagen Inc., 20500 Trans Canada Hwy,
Baie d'Urfé, QC H9X 0A2
U.S.A.: Rolf C. Hagen (U.S.A.) Corp., 305 Forbes Blvd, Mansfield, MA. 02048
UK: Rolf C. Hagen (UK) Ltd, Customer Service Department California Drive, Whitwood Ind Est., Castleford West Yorkshire WF10 5QH
CALL US ON OUR TOLL-FREE NUMBER:
CANADA ONLY: 1-800-554-2436 between 8:00 am and 4:30 p.m. Eastern Standard Time.
Ask for Customer Service.
U.S. ONLY: 1-800-724-2436 between 9:00 a.m. and 4:00 p.m. Eastern Standard Time.
Ask for Customer Service.
U.K. ONLY: Helpline Number 01977 521015. Between 9:00 AM and 5:00 PM, Monday to Thursday and 9:00 AM and 4:00 PM on Friday (excluding
Bank Holidays).
RECYCLING:
RECYCLING: This symbol bears the selective sorting symbol for waste electrical and electronic equipment (WEEE). This means
that this product must be handled pursuant to European Directive 2012/19/EU in order to be recycled or dismantled to minimize its
impact on the environment. Check with your local Environmental Agency for possible disposal instructions or take to an official
council registered refuse collection point. Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of hazardous substances.
WARRANTY:
2 YEAR LIMITED WARRANTY
Your Fluval Aquasky 3.0 LED is guaranteed for defective parts and workmanship for a period of two years from the date of purchase. This
guarantee is valid with proof of purchase only. The guarantee is limited to repair or replacement only and does not cover consequential loss,
loss or damage to livestock and personal property or damage to animate or inanimate objects, irrespective of the cause thereof. This guarantee
is valid only under normal operating conditions for which the unit is intended. It excludes any damage caused by unreasonable use, negligence,
improper installation, tampering, abuse or commercial use. The warranty does not cover wear and tear or parts which have not been adequately
or correctly maintained. Failure of less than 5% of the total number of LEDs shall not be considered a defect under the terms of this warranty.
THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
A
B
