GARANT Digital dial indicator
de
4. Transport
Transport in the original packaging at temperatures between -10 °C and +60 °C. Secure against falling to the ground.
en
5. Device description
Digital dial indicator for measuring lengths and differences in lengths and for taking reference, flatness, positional and run-
bg
out measurements.
External data transmission via proximity cable (USB) or via Power-RS (power USB).
6. Device overview
da
6.1. DIAL INDICATOR
A
fi
1 MENU button
2 SET button
fr
3 DATA button
4 Button (left)
it
5 Button (right)
6.2. BUTTON FUNCTIONS
hr
MENU MENU
lt
SET SET
DATA
nl
Left /
no
right
pl
6.3. DISPLAY OVERVIEW
B
pt
11 Low battery
12 + / - display
ro
13 Keyboard lock
14 Display of 6 digits
ru 15 Hold the measurement value
16 Data transmission
sv 17 Unit of measurement mm / INCH
18 Preset mode
19 Scale
sk
7. Operation
sl
7.1. SWITCHING ON AND OFF, RESETTING
1. Press any button to switch on the dial indicator.
2. If the dial indicator is being switched on for the first time, select the unit of measurement. See UNIT (selection of unit of
es
measurement) [} Page 17].
» The dial indicator will switch to stand-by mode after 20 minutes of inactivity if the [OFF] function has been set to
[Auto]. See OFF (automatic switch-off mode) [} Page 20].
cs
3. Press and hold
4. Press and hold
hu
» The reference value will be lost.
16
Switches between the functions of the two function levels on the dial indicator. The first level con-
tains basic functions; the second contains advanced functions.
 Confirms a selection.
 Switches off the dial indicator.
 Moves to the next step within a function.
 Transfers measurement values.
 Define the display area for the scale.
 Reduce/increase the numerical value step by step.
 Activate the setting for the nominal value and tolerance limits.
SET
for at least 2 seconds to switch directly to stand-by mode.
SET
for at least 4 seconds to completely switch off the dial indicator.
6 Clamping shank Ø8 or 3/8"
7 Ball contact point Ø2/M2.5 or 4-48-UNF
8 Lifting cap
9 Socket for proximity cable
10 Battery insert or power cable socket
20 Lower limit value undershot
21 Upper limit value exceeded
22 Tolerance indicator
23 Lower limit value of scale
24 Upper limit value of scale
25 Unit and scale graduation
26 Tolerance mode
27 MIN/MAX/DELTA mode
