4. PRODUCT DESCRIPTION

4.1 General overview

1 2 3
5
4
10
3
2
1
9

Control panel

1
Knob for the heating functions
2
Display
3
5. CONTROL PANEL

5.1 Turning the appliance on and off

To turn on the appliance:
1. Press the knobs. The knobs come out.
2. Turn the knob for the heating functions to
select a function.
3. Turn the control knob to adjust settings.
To turn off the appliance: turn the knob for the
heating functions to the off position

5.2 Control panel overview

Press to set timer functions.
Press and hold to set the function:
Fast Heat Up.
Press to turn the appliance lamp on
and off.
Press and hold to set the function:
Lock.
Press to confirm your selection.
4
5
6
7
8
.
Control knob
4
Heating element
5
Lamp
6
Fan
7
Cavity embossment
8
Shelf support, removable
9
Shelf positions
10

4.2 Accessories

• Wire shelf
For cake tins, ovenproof dishes, roast
dishes, cookware / dishes.
• Baking tray
For moist cakes, baked items, bread, large
roasts, frozen meals and to catch dripping
liquids, e.g. fat when roasting food on wire
shelf.
• Grill- / Roasting pan
To bake and roast or as pan to collect fat.

5.3 Display indicators

Display with key functions.
The appliance is locked.
Submenu: Assisted Cooking.
Submenu: Cleaning.
Submenu: Settings
Fast Heat Up is activated.
Steam cooking is activated.
Minute minder is activated.
ENGLISH 9
