Technical data
General
Operating modes
Continuous light
one colour
more than one colour
Blink light
one colour
more than one colour
Flash light
one colour
more than one colour
Remark:
Enclosure
Foot bracket
Stand tube
Light element
Degree of protection
Operating temperature
Storage and transport temperature
Clamping capacity of terminals
Weight
Versions with sounder
Sounder enclosure
Sound signal
Frequency
Loudness level
Versions with AC voltage
Operating voltage
(voltage between colour or sound terminal
and terminal "N")
Current consumption at 230 VAC
colour (white) on / sounder off
colour off / sounder on
colour (white) on / sounder on
Power consumption
Insulation class
Test signal:
Connection line or terminal not in order:
Connection line or terminal in order:
Versions with DC voltage
Operating voltage
(voltage between colour and sounder terminal
and terminal "GND")
Tolerance of operating voltage
Current consumption
colour (white) on / sounder off
colour off / sounder on
colour (white) on / sounder on
Power consumption at rated operating voltage
Insultion class
Test signal:
Connected line in order
Connected line not in order
disconnection
short circuit
the colour is continuously on
990 ms turn-on time per colour
220 ms turn-on time, 275 ms turn-off time
blinks 2 times per colour
55 ms turn-on time, 440 ms turn-off time
flashes 4 times per colour
The change of colour always takes place in the order
green – yellow – red – blue – white
thermoplastic
thermoplastic
aluminium
polycarbonate
IP 54 according to EN60529
-25°C...+60°C
-40°C...+70°C
1.5 mm
0.3 kg
thermoplastic
sweep tone
2.8 kHz ... 3.4 kHz
75 dB(A) to appr. 105 dB(A) with 4 adjustable levels
230 VAC , 50 ...60 Hz
< 50 mA
< 27 mA
< 56 mA
< 13 W
II
A connection line and terminal test can be conducted with the
signal at terminal "LM". The voltage between the terminals "LM"
and "N" is measured. Attention! Don't connect operating voltage
to the "LM" terminal.
measured voltage
0 V or operating AC voltage without DC component
measured voltage
operating AC voltage (±20 %) with DC component
24 VDC
±20 %
< 135 mA
< 80 mA
< 190 mA
< 4.6 W
III
A negative voltage (< 24V) relative to terminal "GND"
can be connected to terminal "LM".
the measured current correlates to a load of 10 k
no current
the measured current correlates to a load of less than 2 k
single or stranded wire
2
7
