TRANSPORTATION AND STORAGE

To make it easier to transport the rollator and save space when

storing it, the front wheels can be turned and the a achment of the

rear wheels can be removed (Figure 9).

FRONT WHEELS

To release the front caster lock, press the red latch (Figure 10). Then

pull the front wheels forward and rotate them 180° upward. To use

the rollator again, pull the front casters forward and rotate them

downward. A click means that the casters are in the right posi on;

you can now adjust the seat accordingly.

REAR WHEELS

Then fold the lever (Figure 11). In the last step, press the bu on

and slide the rear caster mechanism downwards. Note that the rear

wheels are always connected to the rollator via the brake cable.

To unfold them, push the rear caster mechanism back into the frame.

A click means that the wheels are in the right posi on. The lever

should now be folded back.

Make sure that the rear wheels are properly secured, and that the

brake works properly.

MOVING AROUND WITH THE HELP OF A WHEELED ROLLATOR

First, check the operation of the rollator on a level, dry surface. If possible, ask another person to help. At

first, take time to test the use of the rollator, and once you become confident in using it, you can start using

it on inclined surfaces.

NOTE: When moving with the rollator, be sure not to move too far away from the

handles. Do not hunch over.

You choose the speed and direction of movement by pushing the rollator yourself. To reduce the speed of

movement, use the brakes. Always use both brakes when braking. Otherwise, the rollator may turn on one

wheel and cause the user to fall.

Obstacles that appear on the road should be circumvented. If there are steps in the road, look for a ramp, if

the obstacle is stairs, use an elevator. If this is not possible, the rollator should be moved over the obstacle.

As far as possible, another person should be asked to help.
