12. Technical Data
The LUNO B.13, certified in compliance with EN 16510-2-1:2022, can only be oper-
ated when the fire box is closed. Multiple connections to the chimney are possible,
see point 4. "Connection of Multiple Devices in Direct Vent Operation".
The following data applies to the chimney characteristics in accordance with EN
13384-1 /-2:
Combustion Values*
Nominal Thermal Output
Room heating output
Exhaust gas temperature
Waste Gas Outlet Temp.
Waste Gas Mass Flow Rate
Min. Supply Pressure at Nominal Thermal Output
Efficiency
CO content
Particulate
OGC
NO
X
Min. required combustion air volume
Depending on the insulation of the building, the nominal thermal output of 6,2 kW
indicated on 20 bis 80 m² (subject to change).
Dimensions:
Stove
Fire box
Weight (Steel/Ceramic/Natural stone)
¹ Vertical flue pipe length
Flue pipe diameter
Pipe diameter of HASE air system**
Wood
6,2 kW
6,2 kW
254 ˚C
305 ˚C
6,2 g/s
12 Pa
80 %
1250 mg/Nm³
40 mg/Nm³
120 mg/Nm³
200 mg/Nm³
25 m³/h
*Test bench performance and values at 13% O
** For separate air supply in low-energy houses and insufficient combustion air supply in the room
where the stove is installed.
Height Width
115,5 - 119,5 cm 51 - 54,5 cm
36 cm 33 cm
2
Depth
44,5 cm
29 cm
123/139/170 kg
min. 25 cm
15 cm
10 cm
