Extendable Riser Bracket Mounting Option:
I. Pull pre-installed brackets out of light fixture.
II. Insert riser brackets into same holes as previous brackets, ensuring bracket edges are facing
correct direction.
III. Adjust LED to desired width and mount light fixture to top of aquarium frame and secure into place
by tightening locking nut on both rim connectors.
IV. Using included Allen key, adjust LED to desired height by loosening and tightening 2 locking
screws on each rim connector.
V. Connect transformer to light fixture electrical supply and plug into power source.
DIMMABLE LED WITH ILLUMINATED TOUCH SWITCH CONTROL:
Illuminated Touch Switch: Switch changes color to indicate the different settings: off
(red illumination), all lights on (white illumination), Blue lights only (blue illumination), Bluetooth mode
(green illumination).
Dimming Feature: Lighting intensity can be dimmed on both the white illumination setting (all lights
on)or the blue illumination setting (only blue lights on) by depressing the switch and keeping finger
on it until preferred lighting intensity is reached. NOTE: Once dimming intensity level is chosen it will
remain fixed at that level, even if fixture is turned off. To change the intensity level it is necessary to
manually depress and hold down the switch.
MAINTENANCE:
For maximum LED performance, it is recommended that the fixture and the LED lens be cleaned on a
weekly basis. Unplug transformer prior to cleaning the light fixture and remove from aquarium. Use
both hands when manipulating this appliance. Wipe exposed surfaces carefully with a damp cloth
to remove any dust or mineral deposits that may collect over time. Do not use detergents or harsh
cleaners as it can damage the light fixture. Make sure all surfaces are dry before re-connecting the
transformer to the power source.
BASIC TROUBLE-SHOOTING:
If the fixture does not work, ensure that all plugs and wires are firmly connected, ie: connection from
fixture to transformer, and connection from transformer to electrical outlet.
Model 16885
Input Volts 100-240 V
Operating Volts 24 V
Size 15 - 24"
Adjustment 38 - 63 cm
No. of LEDs 99
Wattage 22
Lumens 1600
Life in Hours 50 000
FOR AUTHORIZED WARRANTY REPAIR SERVICE:
QUESTIONS? If you have a problem or question about the operation of this product, please let us try
to help you before you return the product to your dealer. Most problems can be handled promptly
with a phone call. Or, if you prefer, you can contact us on our web site at www.fluvalaquatics.com.
When you call (or write), please have all relevant information, such as model number and/or part
numbers available.
CANADA: Consumer Repair, Rolf C. Hagen Inc., 20500 Trans Canada Hwy,
Baie d'Urfé, QC H9X 0A2
U.S.A.: Rolf C. Hagen (U.S.A.) Corp., 305 Forbes Blvd, Mansfield, MA. 02048
UK: Rolf C. Hagen (UK) Ltd, Customer Service Department California Drive, Whitwood Ind Est.,
Castleford West Yorkshire WF10 5QH
CALL US ON OUR TOLL-FREE NUMBER:
CANADA ONLY: 1-800-554-2436 between 8:00 am and 4:30 p.m. Eastern Standard Time.
Ask for Customer Service.
U.S. ONLY: 1-800-724-2436 between 9:00 a.m. and 4:00 p.m. Eastern Standard Time.
Ask for Customer Service.
U.K. ONLY: Helpline Number 01977 521015. Between 9:00 AM and 5:00 PM, Monday to Thursday and
9:00 AM and 4:00 PM on Friday (excluding Bank Holidays).
RECYCLING:
This symbol bears the selective sorting symbol for waste electrical and electronic
equipment (WEEE). This means that this product must be handled pursuant to European
Directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the
environment. Check with your local Environmental Agency for possible disposal instructions
or take to an official council registered refuse collection point. Electronic products not
included in the selective sorting process are potentially dangerous for the environment and human
health due to the presence of hazardous substances.
RED= OFF
WHITE= ON
BLUE= BLUE ONLY
GREEN= BLUETOOTH MODE
16886 16887
100-240 V 100-240 V
24 V 24 V
23 - 35" 35 - 49"
59 - 89 cm 88 - 126 cm
168 252
32 46
2550 3650
50 000 50 000
16888
100-240 V
24 V
46.25 - 61"
117 - 155 cm
110 - 148 cm
(UK only)
336
59
4700
50 000
