If intermediate rope holders are present, the swivelling lever of the arrester runner is gripped and the wire rope
is pulled out of the clip of the intermediate rope holder. After crossing the intermediate rope holder, the wire rope
must be pushed back into the clamp of the intermediate rope holder.
4. Overview AH5 easy
No.
Designation
1
Pushbutton
Swivelling lever
2
Sliding housing
3
Wire rope Ø = 8 mm
4
Table: 1
Mittelmann Sicherheitstechnik GmbH & Co. KG - Bessemerstrasse 25 - DE-42551 Velbert
Phone : +49 (0)2051 / 91219-00 – Fax : +49 (0)2051 / 91219-19 – Email : info@mittelmann.com
- 12 -
Figure: 2
1
4
3
Figure: 3
2
