AR10410T, AR14410T, AR20410T PowerSafe Receivers
The Spektrum™ AR10410T, AR14410T and AR20410T Receivers are full
range with telemetry, and are compatible with all Spektrum™ DSM2
DSMX
technology transmitters.
®
Perform the setup for these receivers through a compatible Spektrum Transmitter
with Forward Programming. The Spektrum PC Programmer can be used for
firmware updates.
Type
Application
Channels
AS3X+
Remote Receivers
Modulation
Telemetry
Bind Method
Failsafe
Power Button
Band
Input Connector
Input Voltage
Resolution
AR10410T 10CH
AR14410T 14CH
AR20410T 20CH
IMPORTANT
: These receivers only use forward programming for the
configuration, do not use the AS3X menu in the main transmitter menu.
WARNING:
propeller should not be installed on the motor during the setup
procedure. Only install the propeller once the throttle has been confirmed to
operate correctly and the failsafe has been set.
As an additional safety feature, we recommend the throttle cut is enabled.
Throttle cut should be engaged any time the aircraft is powered on and not
in operation. The motor will not rotate when throttle cut is in the ON position.
Specifications
PowerSafe DSMX Telemetry Receiver
Available with optional Synapse sensor
(2–4) SRXL2
[3-SPM9747 and 1-SPM4651T Included]
On Receiver, Remote Switch
(2) IC3 Input Connectors with Smart Technology
2048 (4096 for Stabilization)
2.56" x 2.44" x 0.71" (65mm x 62mm x 18mm)
2.56" x 2.44" x 0.71" (65mm x 62mm x 18mm)
2.4" x 2.72" x 0.75" (61mm x 69mm x 19mm)
For electric powered aircraft and if equipped, the
Airplane
20
Remote Receivers
™
DSMX
Integrated
Bind Button, Bind Plug
Yes
2.4GHz
4V–12.6V
1.77 oz (50g)
2.68 oz (76g)
2.82 oz (80g)
EN
and
®
3
