EuroLite LED B-18 Beam Effect Bedienungsanleitung Seite 22

Display
ADDR 001-506
M-DM
MODE
M-AU
M-SO
PRCO PR1-8
SPCO SP01-15
SPMO SP1-6
INVE INVE
DMX-controlled operation
You can control the devices individually via your DMX-controller. Every DMX-channel has a different
occupation with different features. The individual channels and their features are listed under DMX-protocol.
Addressing
The Control Board allows you to assign the DMX starting address, which is defined as the first channel from
which the LED B-18 Beam Effect will respond to the controller.
Please, be sure that you don't have any overlapping channels in order to control each LED B-18 Beam Effect
correctly and independently from any other fixture on the DMX-chain.
If several LED B-18 Beam Effects are addressed similarly, they will work synchronically.
Press the MODE-button and the UP/DOWN-buttons for setting the desired starting address. Now you can
start operating the LED B-18 Beam Effect via your lighting controller.
DMX-protocol
Control-channel 1 - PAN-Rotation
Value
000 - 007 No rotation
008 - 123 Forwards rotation
124 - 131 No rotation
132 - 247 Backwards rotation
248 - 255 No rotation
Control-channel 2 - LED-Effects
Value
000 - 005 Dimmer
006 - 050 Color-change
051 - 100 Fade
101 - 150 Color-change + strobe
151 - 200 Cross-fade
201 - 255 Cross-fade + strobe
Function
DMX address setting
With this function, you can set the desired DMX 512 address via the
Control Board.
DMX mode setting
Automatic program mode
With this function, you can adjust the Auto mode.
Sound-controlled mode
With this function, you can adjust the sound-controlled mode.
Built-in program setting
You can run the internal programs via "PR. 1-8".
Pr. 1 – 4 switching
Pr. 5 – 8 fading
Program speed setting
With this function you can set the program speed.
Motor speed setting
With this function you can set the motor speed.
Display setting
With this function you can to turn the display upside down.
Characteristic
with increasing speed
with decreasing speed
Characteristic
22/24 00073343.DOC, Version 1.0
