Master/Slave operation
The master/slave operation enables that several devices can be synchronized and controlled by one master
device.
On the rear panel of the device you can find an XLR jack and an XLR plug, which can be used for
connecting several devices.
Choose the device which is to control the effects. This device then works as master device and controls all
other slave devices, which are to be connected to the master device via a DMX-cable. Connect the OUT jack
with the IN plug of the next device.
Set the Master device to one of the stand alone modes ("M-AU" or "M-SO") and set each Slave device to the
same DMX address "001".
Connection with the mains
Connect the device to the mains with the power-plug.
The occupation of the connection-cables is as follows:
Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
Lighting effects must not be connected to dimming-packs.
OPERATION
After you connected the spot to the mains, the EUROLITE LED B-18 Beam Effect starts running.
The device has two operating modes. It can be operated in Stand Alone mode via the Control Board or it can
be run in DMX-controlled mode via a DMX controller.
The device features a built-in microphone and a rotary control on the rear panel to adjust the sound
sensitivity.
Stand Alone operation
In the Stand Alone mode, the LED B-18 Beam Effect can be used without controller. Disconnect the LED B-
18 Beam Effect from the controller.
Control Board
The Control Board offers several features: you can e. g. simply set the starting address.
Enter the menu by pressing the MODE-button. You can change the selection by pressing UP or DOWN.
Press ENTER in order to select the desired menu. You can leave every mode by pressing the MODE-button.
The functions provided are described in the following sections.
International
L
N
