When choosing the installation-spot, please make sure that the device is not exposed to extreme heat,
moisture or dust. There should not be any cables lying around. You endanger your own and the safety of
others!
This device must never be operated or stockpiled in sourroundings where splash water, rain, moisture or fog
may harm the device. Moisture or very high humidity can reduce the insulation and lead to mortal electrical
shocks. When using smoke machines, make sure that the device is never exposed to the direct smoke jet
and is installed in a distance of 0.5 meters between smoke machine and device. The room must only be
saturated with an amount of smoke that the visibility will always be more than 10 meters.
The ambient temperature must always be between -5° C and +45° C. Keep away from direct insulation
(particularly in cars) and heaters.
The relative humidity must not exceed 50 % with an ambient temperature of 45° C.
This device must only be operated in an altitude between -20 and 2000 m over NN.
Never use the device during thunderstorms. Over voltage could destroy the device. Always disconnect the
device during thunderstorms.
- - -m
The symbol
between light-output and the illuminated surface must be more than 0.1 meters.
This device is only allowed for an installation via the mounting bracket. In order to safeguard sufficient
ventilation, leave 50 cm of free space around the device.
The housing must never touch surrounding surfaces or objects.
Make sure that the area below the installation place is blocked when rigging, derigging or servicing the
fixture.
Always fix the fixture with an appropriate safety bond.
The maximum ambient temperature T
Operate the device only after having become familiarized with its functions. Do not permit operation by
persons not qualified for operating the device. Most damages are the result of unprofessional operation!
Never use solvents or aggressive detergents in order to clean the device! Rather use a soft and damp cloth.
Please use the original packaging if the device is to be transported. Make sure that you pack the device in
the original state.
Please consider that unauthorized modifications on the device are forbidden due to safety reasons!
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, crash etc.
DESCRIPTION OF THE DEVICE
Features
LED DMX mirror ball effect
•
Half ball with 55 lenses
•
Equipped with 8 x 3 W LEDs
•
20 rotations per minute
•
Operable in stand-alone mode or via DMX interface
•
DMX-512 control possible via any commercial DMX-controller (occupies 11 channels)
•
Sound-control via built-in microphone
•
Microphone-sensitivity adjustable via rotary-control
•
Comfortable addressing and setting via control panel with 4-digit LED screen and four operating buttons
•
Functions: stepless color change; color fade; internal programs; dimmer, strobe settings, rotation
direction and speed adjustable via stand-alone mode and via DMX; Master/Slave
•
Hanging or standing installation possible
•
Mounting bracket for installation on a trussing system included
•
Ready for connection via power cord with safety plug
determines the minimum distance from lighted objects. The minimum distance
= 45° C must never be exceeded.
a
17/24
00073343.DOC, Version 1.0
