Create Warm Wall Bedienungsanleitung Seite 7

Disconnecting means with contact separation on all poles must be incor-
•
porated in the fixed wiring in accordance with wiring regulations.
Do not use this heater if it has been dropped. Do not use if there are visi-
•
ble signs of damage to the heater.
Use this product on a horizontal and stable surface, or attach it to the
•
wall, as appropriate.
Do not use this heater in small rooms when occupied by persons who are
•
not capable of leaving the room alone, unless there is constant supervision.
To reduce the risk of fire, keep textiles, curtains or other flammable ma-
•
terials at least 1 m away from the air outlet.
The heater must be installed at least 1.8 m above the floor.
•
This heater can be installed on the wall, for installation follow the following steps:
1. Mark the holes on the wall with a separation of 170 mm from each other, with the help of a
drill make the holes in the wall using a drill bit Ø8 mm.
Attention: Make sure to respect the safety distances between lateral objects of at least 60
mm and the ground at least 2100 mm.
2. Insert the plastic plug into the hole and secure the screws inside using a star screwdriver.
3. Place the product on the wall with fixed screws, inserting the holes marked in the draw-
ing and then gently move the device to the left and down so that the heater is correctly
positioned.
Warning: Before using the heater, make sure it is securely mounted on the wall.
1. Air vent
2. Control Panel
3. Engine body
4. Paws
WALL INSTALLATION
PARTS LIST
1
2
3
4
E NGLI SH
7
