Connect / Limits
Connect MA onPC command wing always direct to your PC or notebook; use a USB 2.0 – cable. For
all other hardware e.g mouse, keyboard, MA – hardware and so on.use another USB- port or a hub.
MA onPC command wing is capable for maximal 2048 parameters via 2 DMX-ports. Boost the quantity
of parameters of the command wing by the use of other MA – hardware. The absolute maximum is
limited by the onPC – software: 4096 parameters.
Available parameters / DMX OUT ports:
PC + MA onPC command wing:
PC + MA onPC command wing + 2Port Node
PC + MA onPC command wing + 2Port Pro Node
PC + MA onPC command wing + NSP (as 4-Port Node)
PC + MA onPC command wing + NPU (as 4-Port Node)
2048 Parameter / 2 DMX OUT
2560 Parameter / 4 DMX OUT
3072 Parameter / 4 DMX OUT
4096 Parameter / 6 DMX OUT
4096 Parameter / 6 DMX OUT
