Connect / examples
MA onPC command wing
MA onPC command wing
MA onPC command wing
PC with onPC
USB direct
Max. 3072 parameters / 4 DMX OUT
(only the significant node counts)
+
PC with onPC
USB direct
+
PC with onPC
USB direct
Max. 2048 parameters / 2 DMX OUT
keyboard/mouse
USB -Hub
Ethernet
Max. 4096 parameters / 6 DMX OUT
or
NSP or NPU
Ethernet
