Inserting the 12 V adapter
1. Remove the 12 V adapter (8) from
the side of the device as necessary by
pushing the latch (7) on the bottom of
the 12 V adapter away from the device
and pulling up on the 12 V adapter.
2. Slide the 12 V adapter (8) into the bat-
tery holder on the back of the device.
Inserting the 12 V battery
1. Slide the battery (12) into the 12 V
adapter (8).
Removing the 12 V battery
1. Press the release buttons (11) on the bat-
tery (12).
2. Pull the battery (12) up and out of the
12 V adapter (8).
Removing the 12 V adapter
1. Pull the latch (7) on the bottom of the
12 V adapter (8) towards you.
2. Pull the 12 V adapter up and out.
3. For storage, you can slide the 12 V ad-
apter (8) onto the guide (14) on the side
of the device.
Switching on/off
1. To switch the device on, press the
On/Off switch (2). The LED lamp illumi-
nates with maximum brightness.
2. To switch the device off, press the
On/Off switch (2).
Changing the
illumination mode
When you switch the device on, the LED
lamp illuminates with maximum brightness.
Switch the illumination mode by pressing
the switch (1) next to the On/Off switch (2).
22
The repeating order of modes is:
100% - 50% - flashing

Working instructions

Do not stare into the battery-powe-
red LED flood lamp while it is on.
Swivelling the battery-
powered LED flood lamp
1. Loosen the adjusting screw (4).
2. Rotate the handle (3) of the battery-
powered LED flood lamp to the desired
position.
3. Tighten the adjusting screw (4).
Hanging the battery-
powered LED flood lamp
Hanging the battery-powered
LED flood lamp on the hook
1. Fold the hook (5) outwards.
2. Hang the device horizontally.
Do not catch your fingers when hoo-
king and unhooking the hook (5).
Hanging the battery-powered
LED flood lamp using the key-
hole bore
1. Insert a screw or nail at the desired po-
sition on a wall.
2. The screw/nail head can have a dia-
meter of 7 - 10 mm.
3. Leave the screw/nail head protruding
at a distance of approx. 10 mm from
the wall.
4. Hang the device on the keyhole bore (15).
Hanging the battery-powered
LED flood lamp on the baseplate
1. Insert a screw or nail at the desired po-
sition on a wall.
