eQ-3 homematic IP basic HmIP-WLAN-HAP-B Installations- Und Bedienungsanleitung Seite 17

Start-up
data.
• Scratch off the QR Code sticker
(B) and the text on the back of the
device completely.
Figure 3
• Start the Homematic IP app on
your smartphone.
• Follow the instructions in the app
to set up the Homematic IP Access
Point – basic.
• Scan the OR code on the back side
of the device.
Figure 4
• Alternatively, you can enter the
SGTIN and key of the device sticker
manually into the app.
1 2 3 4 5 6
Figure 5
If you have entered the data of the
device sticker manually, you are
now asked to enter the password
(PW).
• Connect the supplied USB plug-in
power supply unit to the interface
(C)) and to a mains socket.
C
Figure 6
• For the transmission of data, the
17
