| REAR PANEL
REAR PANEL OVERVIEW
The HP-10 is equipped with high-quality
connectors and features balanced and
unbalanced inputs and outputs for maximum
reliability and versatility.
Using the XLR and RCA connectors, the
HP-10 can be placed in a system to easily
switch between headphone and loudspeaker
listening. The PSU input is dedicated to the
PSU-10 EVO external power supply to further
enhance the unit's performance.
1
3
ANALOGUE OUTPUTS
1
RCA unbalanced
2
XLR balanced
ANALOGUE INPUTS
3
RCA unbalanced
4
XLR balanced
In addition, the USB-C input allows you to
connect smartphones, tablets and computers
to listen to music stored on digital libraries.
IMPORTANT
The optional USB-C input is only available on
the HP-10 DELUXE.
5
2
6
4
7
11
8
9
DIGITAL INPUT
6
USB-C (optional)
POWER AND OTHERS
5
PSU IN
7
GN LINK
8
AC plug IEC standard
9
USB-C (firmware updates)
