Installation
The installation can only be done by a properly qualifi ed person! Disconnect power
supply before installation!
1) Place the thermostat to the desired location on the pipe (
F
part of the thermostat abut on its surface.
2) Using a spring, secure the thermostat on the spot (
3) Loosen the screw
4) Connect the wires according to
5) Put back the cover and secure it with the screw.
i
When using stranded wire, use ferrules (
For a more accurate temperature measurement, it is recommended to use a heat
conducting paste and to remove the dirt from contact surface
Settings
After thermostat instalation, to access the adjusting elements, remove the screw
the transparent cover of the controls. It is then possible to set the controls. Turn the control
1
knob to the desired position:
a) ON - the thermostat is constantly ON regardless of temperature,
b) OFF - the thermostat is constantly OFF regardless of temperature,
c) position 30 °C to 80 °C - the thermostat switches ON the output when the set
temperature is exceeded and switches OFF when the temperature fall by set hysteresis
2
using .
i
Anti-scale protection - if the pump is inactive for more than 24 hours, it will be
switched ON for about 15 seconds.
B
and remove the bottom safety cover
Fig.4
Fig.2
Fig.5
(see detail
Fig.6
).
Fig.2
) so that the measuring
).
C
by sliding it upwards.
).
F
.
C
and lift
