Description of elements and LEDs
The electronic thermostat PT02 is used to switch circulating pumps depending on the set
temperature and hysteresis (
Fig.4b
( ).
The advantage is the adjustable hysteresis (2 °C to 20 °C), easy adjustment of the
control temperature and easy installation directly on the surface of the pipe. In addition,
it contains anti-scale protection. Its mounting is carried out by a tension spring. Controls
and connection terminals are secured against unwanted manipulation with the lock screw.
a screw for access to the adjusting
A
elements
a screw for access to the terminal blocks
B
C
safety cover of terminal
D
output terminals (potential-free)
Imax = 10 A/ 250 V AC
LED
8
Fig.4a
). It can also be used as an emergency thermostat
RE
LIT = relay ON indication
ERR
BLINKING = temperature sensor error
PWR
LIT = power ON indication
power terminals (230 V/ AC)
E
F
sensing area
control temperature setting
1
(30 °C to 80 °C)
hysteresis setting
2
(2 °C to 20 °C)
FUNCTION
