EN
MAIN PARAMETERS AND PARTS LIST
No. Parameters Names
1 Input power voltage
2 Motor power
3 Speed
4 Running surface
5 Max user weight
6 Expand dimensions

PACKING LIST

No. Name
1 Complete machine
2 Supporting base
3 Accessory Bag
ACCESSORY BAG LIST
NO. Name
1 Inner hexagon spanner 5mm
2 Inner hexagon spanner 6mm
3 Safety key
4 Silicone oil

INSTALLATION INSTRUCTIONS

When installing, simple fix all screws first, then tighten the screws when the installation of frame is done.
1. Put the machine flat on the ground. Remove the knob with the direction shown in the picture below.
Then stand the columns and console with the direction shown in the picture below.
2. Remove the preinstalled screws M8*22 on the supporting frame and then tighten the supporting frame
with screw M6*12 on the base. Use 5# hexagon wrench and screw M6*12 to lock and fix the base(two
screws for each side).
4
Description
220-240V~; 50/60Hz
1.5HP
1.0-10 Km/h
400*1100 mm
90KG
1470*635*1120mm
units
set
pc
pc
NO. Name
QTY
1 5 User manual
1 6 MP3 cable
1 7 Screw M8*25
1 8 Screw M6*12
Qty
1
2
1
QTY
1
1
2
4
