iNDEX
Pruduct illustration
Part description
List of items
Specification

Field of application

Assembly
Dismantling
Handling + details
Accessories
Declaration of conformity
liST Of iTEMS
1 Hull
1 Seat-board bow
1 Seat-board stern/middle
1 Carrying belt
2 Safety and carrying-lines
1 Repair kit incl. valve key and bayonet
adapter
SPECifiCaTiON
Length:
Beam:
Net weight:
No of persons:
Carrying capacity:
Operating pressure:
Motor output:
Motor weight:
Sail area:
Wind force:
WW-Class:
Standard:
Category:
Page
2
2
7
7
7
7
8
8
9
11
455 cm
100 cm
29.5 kg
3 adults
380 kg
0,3 bar
4.4 kw - 6 HP
30 kg
7 m²
4 Beaufort
3
ISO-EN 6185/II
D
fiElD Of aPPliCaTiON
► Canoe or rowing boat for 3 persons,
on lakes, rivers and sheltered coastal
close waters.
► Motorisation to max 4.4kW/ 6HP.
► Sail boat, 7 m² sail area, to max. wind
force 4 Beaufort.
► White-water suited boat to class grade 3
- none obstructive passages, high inordi-
nate waves, large swell, rolling, swirling
water, surge and torrent wash
aSSEMBly
► Open and empty the carton, of your boat
and the footrests.
► Check the list of items to ensure no parts
are missing.
► Remove the wrapping foil and unroll the
boat.
► Inflate bottom and side tubes till they
reach approximate final shape.
► Remove the knurled nuts of the seat-
boards and insert them from underneath
into the seat-board eyelets, fasten the
nuts.
important: short seat-board forward,
long seat-board aft or midships
► Now only inflate your boat to full oper-
ating pressure (0.3 bar).
► Fasten safety line to the eyelet lip on the
port- and starboard side.
DiSMaNTliNG
► Choose clean ground for dismantling
and packing.
► Remove all loose parts from the boat
(seats, spray cover, personal items, ...)
► Deflate the boat.
► Remove seat-boards.
► Clean and dry your boat and the accesso-
ries to avoid damage by grit!
► Check your boat for possible damage,
and repair such as soon as possible, rea-
dy for next use!
