2.3.1Reading the Powerline indicator
light
The integrated Powerline indicator light (LED)
shows the status for the devolo Magic 1 WiFi mini
by illuminating and/or flashing:
LED Flashing
haviour
1 Red LED Lights up for
up to 75 sec.
2 Red LED Flashes at in-
tervals of 0.5
sec. (on/off)
be- Meaning
Start-up process
Status 1:
The reset of the devolo Magic adapter was
successful. The PLC/reset button has been
pressed and held for 10 seconds.
Status 2:
The devolo Magic adapter (once again) has
the factory default settings. Since the last
reset, no pairing with another devolo Magic
adapter has taken place.
Connect the adapter
devolo Magic adapter to create a full-
fledged PLC network as described in
Chapter 2.3 Pairing – Establishing a
Powerline connection.
Introduction 14
LED status display
(web interface*)
Cannot be disabled
Cannot be disabled
with another
devolo Magic 1 WiFi mini
