TECHnICAl InfORMATIOn
Cable inlet for electrical
connection
Gas connection
Connection to equipotential
system
Water connection
Greywater drain
Burnt oil drain
Combustion flue gas
exhaust
THE PRESENT MANUAL IS PROPERT Y OF THE MANUFACTURER. ANY REPRODUCTION, EVEN PARTIAL, IS PROHIBITED.
MoDEL A
29 26
94
260 94
450
MoDEL B
49
94 710
900
- 41 - 41 41
224
63
323.5
94
63
222.5
814 63
222.5
814 63
