2.3 Emergency control (standard)
In case of an emergency, the system can be operated directly on the main valve block, as shown in Figure 2.1.
Each section on the valve block represents a function. By pulling or pushing with the lever the cylinder either
extends or retracts. The first section (section operated in Figure 2.1) operates the main cylinders.
Figure 2.1 Instruction emergency control
Highly dangerous:
Only the hydraulic safeties are active when using emergency control.
Warning:
Only operate the emergency control when the in-cab control is disabled or
cannot be reached.
Warning:
Do not use the emergency control for regular operation.
Do not leave the emergency control in the valve block after operating.
Tip:
Keep the emergency lever in the cab, and out of reach of non-operators.
