// INSTALLING THE RANGE EXTENDER / BOTTLE CAGE

DANGER
DANGER OF BATTERY DAMAGE!
If the screws in the threaded eyelets of the bottle cage mount are too long, they can
protrude into the frame and damage the battery.
• The screws must not protrude more than 8 mm into the thread in the
frame.
• Only use the mounting material supplied by Propain for the range extender.
RISK OF DAMAGE DUE TO COLLISION!
Incorrect installation of the range extender can lead to damage to the frame.
• Mount the range extender in the highest possible
position.
• Make sure that the range extender or other parts
in the holder do not collide with the aluminum
rocker!
• Follow the SRAM instructions for fitting the range
extender. Scan the QR code for more information.
68
max 8 mm!
4 Nm
4 Nm
