D O O R S Y S T E M C H E C K L I S T T E X T
Hardware
1.0 Door
1.1 Manual operation of the door
1.2 Fastenings / connections
1.3 Pivot points
1.4 Rollers / roller holder
1.5 Seals
1.6 Door guide / tracks
1.7 Track connection
1.8 Door leaf
1.9 Locking devices / stoppers
2.0 Counterbalance
2.1 Torsion springs
2.2 Safety elements
2.3 Cables
2.4 Cable fastening
2.5 Cable drums
2.6 Concentricity of T-shaft
3.0 Other equipment
3.1 External locking mechanism
3.2 Internal locking mechanism
4.1 Play between door leaf and
tracks
4.2 Light incidence from the inside
4.3 Pressing of the frame seal
4.4 Alignment of the centre hinges
5.0 Actuator / control
5.1 Actuator / track / console
5.2 Electrical leads / connections
5.3 Emergency unlocking
5.4 Limit shutdown
5.5 Endabschaltung
6.0 Documentation
6.1 Label
6.2 Warnings
6.3 Operating instructions
6.4 User's manual
Caution: An inspection is not the same thing as maintenance!
14
Applicable Properties to
be inspected
Smooth running
State / lubrication
State / lubrication
Alignment / fastening
Alignment / fastening
Alignment / state
2 safety windings
State
State / function
State / function
State / adjustment
State / adjustment
State / adjustment
State
State / fastening
State
State / fastening
State / fastening
State / fastening
complete / legible
complete / legible
complete / legible
complete / legible
User's manual for CARGO doors
Issued: 5/2014
O.K.
Remarks
