Technical Information
Battery
Adaptor Port
Output
Motor Power
Battery Charging Time
Operation Period
Dust Canister Capacity
Filter
Service Life
Handheld Operation Period: High:>=14 min., Medium:>=24 min., Low:>=46 min.
Preparing the Vacuum Cleaner
Remove all packaging materials, the vacuum cleaner and the accessories. Remove any
adhesive foils, adhesive labels and papers from the appliance.
Installation the Vacuum Cleaner
•
For the installation of the vacuum cleaner, raise the roller cover (5) first, insert the brush
you want to use and close the brush cover.
•
Insert the wand (4) to the compartment inside the brush reservoir and make sure that
the lock is properly seated; a click shall be heard.
•
Insert the motor head of the vacuum cleaner to the compartment at the end of the wand
and make sure that the lock is properly seated; a click shall be heard.
•
Insert the battery (9) of the appliance to the reservoir inside the head compartment and
make sure that it is seated; a click shall be heard.
Charging the Battery
Turn off the the vacuum cleaner before charging!
•
Place the vacuum cleaner to the charging dock. You shall discharge the battery
completely at initial operation, and then recharge it completely.
•
Connect the dock to the mains using the adaptor. Charge level of the battery is displayed
with a light indicator.
•
Battery is completely recharged after approx. 3-5 hours.
•
This appliance is equipped with battery overcharging protection. Charging shall be
stopped when maximum charge level is reached.
: 25.9V 2500mAh Li-ion Battery
: 100-240V/50-60Hz 0.8A
: 30V 800mA 24 W
: 350 W BLDC Motor (Unit) 20 W DC Motor (Brushed)
: 3-3.5 hours
: High: >=12 min., Medium:>=20 min., Low:>=40 min.
: 0.5 Litre
: H10 HEPA
: 10 years
33
